Agilent Technologies InfiniiVision 5000 Series Programmer's Guide

64 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:DISPlay:LABel {{0 |
OFF} | {1 | ON}} (see
page 213)
:DISPlay:LABel? (see
page 213)
{0 | 1}
:DISPlay:LABList
<binary block> (see
page 214)
:DISPlay:LABList?
(see page 214)
<binary block> ::= an ordered
list of up to 75 labels, each 10
characters maximum, separated by
newline characters
:DISPlay:PERSistence
<value> (see
page 215)
:DISPlay:PERSistence?
(see page 215)
<value> ::= {MINimum | INFinite}}
:DISPlay:SOURce
<value> (see
page 216)
:DISPlay:SOURce? (see
page 216)
<value> ::= {PMEMory{0 | 1 | 2 |
3 | 4 | 5 | 6 | 7 | 8 | 9}}
:DISPlay:VECTors {{1
| ON} | {0 | OFF}}
(see page 217)
:DISPlay:VECTors?
(see page 217)
{1 | 0}
Table 7 :DISPlay Commands Summary (continued)
Command Query Options and Query Returns
Table 8 :EXTernal Trigger Commands Summary
Command Query Options and Query Returns
:EXTernal:BWLimit
<bwlimit> (see
page 220)
:EXTernal:BWLimit?
(see page 220)
<bwlimit> ::= {0 | OFF}
:EXTernal:IMPedance
<value> (see
page 221)
:EXTernal:IMPedance?
(see page 221)
<impedance> ::= {ONEMeg | FIFTy}
:EXTernal:PROBe
<attenuation> (see
page 222)
:EXTernal:PROBe? (see
page 222)
<attenuation> ::= probe
attenuation ratio in NR3 format
n/a :EXTernal:PROBe:ID?
(see page 223)
<probe id> ::= unquoted ASCII
string up to 11 characters
:EXTernal:PROBe:STYPe
<signal type> (see
page 224)
:EXTernal:PROBe:STYPe
? (see page 224)
<signal type> ::= {DIFFerential |
SINGle}
:EXTernal:PROTection[
:CLEar] (see
page 225)
:EXTernal:PROTection?
(see page 225)
{NORM | TRIP}
