70 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:MEASure:FREQuency
[<source>] (see
page 283)
:MEASure:FREQuency?
[<source>] (see
page 283)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= frequency in
Hertz in NR3 format
:MEASure:NWIDth
[<source>] (see
page 284)
:MEASure:NWIDth?
[<source>] (see
page 284)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= negative
pulse width in seconds-NR3 format
:MEASure:OVERshoot
[<source>] (see
page 285)
:MEASure:OVERshoot?
[<source>] (see
page 285)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= the percent of
the overshoot of the selected
waveform in NR3 format
:MEASure:PERiod
[<source>] (see
page 287)
:MEASure:PERiod?
[<source>] (see
page 287)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= waveform
period in seconds in NR3 format
:MEASure:PHASe
[<source1>]
[,<source2>] (see
page 288)
:MEASure:PHASe?
[<source1>]
[,<source2>] (see
page 288)
<source1,2> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= the phase
angle value in degrees in NR3
format
:MEASure:PREShoot
[<source>] (see
page 289)
:MEASure:PREShoot?
[<source>] (see
page 289)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= the percent of
preshoot of the selected waveform
in NR3 format
:MEASure:PWIDth
[<source>] (see
page 290)
:MEASure:PWIDth?
[<source>] (see
page 290)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= width of
positive pulse in seconds in NR3
format
n/a :MEASure:RESults?
<result_list> (see
page 291)
<result_list> ::=
comma-separated list of
measurement results
Table 12 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
