Commands Quick Reference 4
Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 73
:MEASure:VPP
[<source>] (see
page 311)
:MEASure:VPP?
[<source>] (see
page 311)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= voltage
peak-to-peak of the selected
waveform in NR3 format
:MEASure:VRATio
[<source1>]
[,<source2>] (see
page 288)
:MEASure:VRATio?
[<source1>]
[,<source2>] (see
page 312)
<source1,2> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= the ratio
value in dB in NR3 format
:MEASure:VRMS
[<source>] (see
page 313)
:MEASure:VRMS?
[<source>] (see
page 313)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= calculated dc
RMS voltage in NR3 format
n/a :MEASure:VTIMe?
<vtime>[,<source>]
(see page 314)
<vtime> ::= displayed time from
trigger in seconds in NR3 format
<return_value> ::= voltage at the
specified time in NR3 format
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
:MEASure:VTOP
[<source>] (see
page 315)
:MEASure:VTOP?
[<source>] (see
page 315)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= voltage at the
top of the waveform in NR3 format
:MEASure:XMAX
[<source>] (see
page 316)
:MEASure:XMAX?
[<source>] (see
page 316)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= horizontal
value of the maximum in NR3
format
:MEASure:XMIN
[<source>] (see
page 317)
:MEASure:XMIN?
[<source>] (see
page 317)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= horizontal
value of the maximum in NR3
format
Table 12 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
