4 Commands Quick Reference
n/a :MEASure:TVALue?
<value>,
[<slope>]<occurrence>
[,<source>] (see
page 304)
<value> ::= voltage level that
the waveform must cross.
<slope> ::= direction of the
waveform when <value> is crossed.
<occurrence> ::= transitions
reported.
<return_value> ::= time in
seconds of specified voltage
crossing in NR3 format
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
:MEASure:VAMPlitude
[<source>] (see
page 306)
:MEASure:VAMPlitude?
[<source>] (see
page 306)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= the amplitude
of the selected waveform in volts
in NR3 format
:MEASure:VAVerage
[<source>] (see
page 307)
:MEASure:VAVerage?
[<source>] (see
page 307)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= calculated
average voltage in NR3 format
:MEASure:VBASe
[<source>] (see
page 308)
:MEASure:VBASe?
[<source>] (see
page 308)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<base_voltage> ::= voltage at the
base of the selected waveform in
NR3 format
:MEASure:VMAX
[<source>] (see
page 309)
:MEASure:VMAX?
[<source>] (see
page 309)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= maximum
voltage of the selected waveform
in NR3 format
:MEASure:VMIN
[<source>] (see
page 310)
:MEASure:VMIN?
[<source>] (see
page 310)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= minimum
voltage of the selected waveform
in NR3 format
Table 12 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
