86 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:TRIGger:IIC[:SOURce]
:CLOCk <source> (see
page 457)
:TRIGger:IIC[:SOURce]
:CLOCk? (see
page 457)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 } for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:IIC[:SOURce]
:DATA <source> (see
page 458)
:TRIGger:IIC[:SOURce]
:DATA? (see page 458)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 } for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:IIC:TRIGger:
QUALifier <value>
(see page 459)
:TRIGger:IIC:TRIGger:
QUALifier? (see
page 459)
<value> ::= {EQUal | NOTequal |
LESSthan | GREaterthan}
:TRIGger:IIC:TRIGger[
:TYPE] <type> (see
page 460)
:TRIGger:IIC:TRIGger[
:TYPE]? (see
page 460)
<type> ::= {STARt | STOP | READ7
| READEprom | WRITe7 | WRITe10 |
NACKnowledge | ANACknowledge |
R7Data2 | W7Data2 | RESTart}
Table 24 :TRIGger:IIC Commands Summary (continued)
Command Query Options and Query Returns
Table 25 :TRIGger:LIN Commands Summary
Command Query Options and Query Returns
:TRIGger:LIN:ID
<value> (see
page 463)
:TRIGger:LIN:ID? (see
page 463)
<value> ::= 7-bit integer in
decimal, <nondecimal>, or
<string> from 0-63 or 0x00-0x3f
(with Option AMS)
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn" where n ::=
{0,..,9 | A,..,F} for hexadecimal
:TRIGger:LIN:SAMPlepo
int <value> (see
page 464)
:TRIGger:LIN:SAMPlepo
int? (see page 464)
<value> ::= {60 | 62.5 | 68 | 70
| 75 | 80 | 87.5} in NR3 format
:TRIGger:LIN:SIGNal:B
AUDrate <baudrate>
(see page 465)
:TRIGger:LIN:SIGNal:B
AUDrate? (see
page 465)
<baudrate> ::= integer from 2400
to 625000 in 100 b/s increments
