Agilent Technologies InfiniiVision 5000 Series

Commands Quick Reference 4
Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 87
:TRIGger:LIN:SOURce
<source> (see
page 466)
:TRIGger:LIN:SOURce?
(see page 466)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:LIN:STANdard
<std> (see page 467)
:TRIGger:LIN:STANdard
? (see page 467)
<std> ::= {LIN13 | LIN20}
:TRIGger:LIN:SYNCbrea
k <value> (see
page 468)
:TRIGger:LIN:SYNCbrea
k? (see page 468)
<value> ::= integer = {11 | 12 |
13}
:TRIGger:LIN:TRIGger
<condition> (see
page 469)
:TRIGger:LIN:TRIGger?
(see page 469)
<condition> ::= {SYNCbreak}
(without Option AMS)
<condition> ::= {SYNCbreak | ID}
(with Option AMS)
Table 25 :TRIGger:LIN Commands Summary (continued)
Command Query Options and Query Returns
Table 26 :TRIGger:TV Commands Summary
Command Query Options and Query Returns
:TRIGger:TV:LINE
<line number> (see
page 480)
:TRIGger:TV:LINE?
(see page 480)
<line number> ::= integer in NR1
format
:TRIGger:TV:MODE <tv
mode> (see page 481)
:TRIGger:TV:MODE?
(see page 481)
<tv mode> ::= {FIEld1 | FIEld2 |
AFIelds | ALINes | LINE |
VERTical | LFIeld1 | LFIeld2 |
LALTernate | LVERtical}
:TRIGger:TV:POLarity
<polarity> (see
page 482)
:TRIGger:TV:POLarity?
(see page 482)
<polarity> ::= {POSitive |
NEGative}
:TRIGger:TV:SOURce
<source> (see
page 483)
:TRIGger:TV:SOURce?
(see page 483)
<source> ::= {CHANnel<n>}
<n> ::= 1-2 or 1-4 integer in NR1
format
:TRIGger:TV:STANdard
<standard> (see
page 484)
:TRIGger:TV:STANdard?
(see page 484)
<standard> ::= {GENeric | NTSC |
PALM | PAL | SECam | {P480L60HZ |
P480} | {P720L60HZ | P720} |
{P1080L24HZ | P1080} | P1080L25HZ
| {I1080L50HZ | I1080} |
I1080L60HZ}
