(a) Cut a length of the selected heat shrinkable sleeve that is equal to the length of the crimp
area of the terminal plus 0.5 inch.
Make sure that the sleeve has the smallest diameter that can move over the terminal and
the wire.
NOTE: Refer to Subject 20-00-11 for alternative heat shrinkable sleeves.
(b) Put the sleeve on the wire.
(3) If the selection is a cold shrinkable sleeve:
(a) Make a selection of a cold shrinkable sleeve from Table 3.
NOTE: The number after the dash in the part number of a cold shrinkable sleeve is the
length of the sleeve, in inches, after the sleeve is installed.
(b) Put the sleeve on the wire.
C. Assembly of BACT12BC, BACT12BD, BACT12BE, BACT12BF and BACT12BG Terminals
Table 4
CRIMP TOOLS
Terminal Lug Crimp Tool
Crimp Barrel
Size for
Aluminum
Wire
(AWG)
Basic Unit Head Die Set
Part Number Supplier Part Number Supplier Part Number Suppiler
2 AL 1804700-1 AMP 1752787-1 AMP 999-63006-100 Tensolite
1/0 AL 1804700-1 AMP 1752787-1 AMP 999-63007-100 Tensolite
2/0 AL 1804700-1 AMP 1752787-1 AMP 999-63008-100 Tensolite
4/0 AL 1804700-1 AMP 1752787-1 AMP 999-63010-100 Tensolite
(1) Make a selection of a terminal from Table 1.
(2) Make a selection of a crimp tool from Table 4.
(3) Put the wire in the crimp barrel of the terminal. Refer to Figure 8.
Make sure that:
• All of the conductor strands are in the crimp barrel
• The end of the wire insulation is against the funnel.
ASSEMBLY OF BACT12BC, BACT12BD, BACT12BE, BACT12BF AND BACT12BG ALUMINUM
TERMINALS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-07
Page 7
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
