10 If the module you are installing is an expansion module, engage the Y-rails of the new module in your
library configuration. Ensure that the Y-rails are properly aligned, and the thumbscrews are tightened.
1 Front Y-rail
2 Rear Y-rail
3 Y-rail (this end up)
4 Squeeze here to release
1
3
2
4
