IPv6 Multicast Commands
435
ProSafe Managed Switch
Example: The following shows example CLI display output for the command.
(Switch) #show ipv6 mld-proxy
Interface Index............................................. 1/0/3
Admin Mode................................................ Enable
Operational Mode......................................... Enable
Version......................................................... 3
Num of Multicast Groups............................. 0
Unsolicited Report Interval.......................... 1
Querier IP Address on Proxy Interface........ fe80::1:2:5
Older Version 1 Querier Timeout................ 00:00:00
Proxy Start Frequency.................................
show ipv6 mld-proxy interface
This command displays a detailed list of the host interface status parameters. It displays the
following parameters only when you enable MLD-Proxy.
Format show ipv6 mld-proxy interface
Modes
• Privileged EXEC
• User EXEC
Interface Index
The column headings of the table associated with the interface are as follows:
Number of Multicast Groups
The number of multicast groups that are associated with the MLD-Proxy
interface.
Unsolicited Report Interval
The time interval at which the MLD-Proxy interface sends unsolicited group
membership report.
Querier IP Address on Proxy
Interface
The IP address of the Querier, if any, in the network attached to the
upstream interface (MLD-Proxy interface).
Older Version 1 Querier
Timeout
The interval used to timeout the older version 1 queriers.
Proxy Start Frequency
The number of times the MLD-Proxy has been stopped and started.
Term Definition
The unit/slot/port of the MLD-proxy.
Term Definition
Ver
The MLD version.
Query Rcvd
Number of MLD queries received.
Report Rcvd
Number of MLD reports received.
Report Sent
Number of MLD reports sent.
Field Description
