Quality of Service (QoS) Commands
460
ProSafe Managed Switch
mark ip-dscp
This command marks all packets for the associated traffic stream with the specified IP DSCP
value.
The <dscpval> value is specified as either an integer from 0 to 63, or symbolically through
one of the following keywords: af11, af12, af13, af21, af22, af23, af31, af32, af33, af41, af42,
af43, be, cs0, cs1, cs2, cs3, cs4, cs5, cs6, cs7, ef.
Format mark ip-dscp <dscpval>
Mode
Incompatibilities
mark ip-precedence
This command marks all packets for the associated traffic stream with the specified IP
Precedence value. The IP Precedence value is an integer from 0 to 7.
Note: This command may not be used on IPv6 classes. IPv6 does not
have a precedence field.
police-simple
This command is used to establish the traffic policing style for the specified class. The simple
form of the police command uses a single data rate and burst size, resulting in two outcomes:
conform and violate. The conforming data rate is specified in kilobits-per-second (Kbps) and
is an integer from 1 to 4294967295. The conforming burst size is specified in kilobytes (KB)
and is an integer from 1 to 128.
For each outcome, the only possible actions are drop, set-cos-transmit, set-dscp-transmit,
set-prec-transmit, or transmit. In this simple form of the police command, the conform action
defaults to transmit and the violate action defaults to drop.
Mode
Policy-Class-Map Config
Incompatibilities
Drop, Mark IP DSCP, IP Precedence, Police
Policy-Class-Map Config
Drop, Mark CoS, Mark IP Precedence, Police
Format mark ip-precedence <0-7>
Mode
Policy-Class-Map Config
Incompatibilitie
s
Drop, Mark CoS, Mark IP Precedence, Police
Policy Type
In
