Commands listed in alphabetical order

Examples

BUS:B1:CAN:TH

Reshold 5

sets the threshold to 5 V.

BUS:B1:CAN:THReshold? might return :BUS:B1:CAN:THRESHOLD 0.0E+0

indicating th

e threshold is set to 0.0 V.

BUS:B<x>:DISplay:FORMat

This command sets or queries how the data is represented in the bus form for the

speciﬁed bus. The bus is speciﬁed by x.

Group

Bus

Syntax

BUS:B<x>:DISplay:FORMat {HEX|BINARY|MI XEDASCII|MIXEDH EX|

ASCII|DECIMAL|MIXED}

BUS:B<x>:DISplay:FORMat?

Arguments

NOTE. Different bus types support only a subset of these arguments.

HEX speciﬁes hexadecimal format.

BINARY speciﬁes binary format.

MIXEDASCII speciﬁes mixed ASCII format.

MIXEDHEX speciﬁes mixed hexadecimal format.

ASCII speciﬁes ASCII format.

DECIMAL speciﬁes decimal format.

MIXED speciﬁes mixed format.

Examples

BUS:B1:DISplay:FORMat BINARY sets the format to binary.

BUS:B1:DISplay:FORMat? might return :BUS:B1:DISPLAY:FORMAT HE X

indicating the format is set to hexadecimal.

BUS:B<x>:DISplay:LAYout

This command sets or queries what to display for the speciﬁed bus. The bus

is speciﬁed by x.

Group

Bus

2-132 MSO54, MSO56, MSO58, MSO58LP Programmer
