Tektronix MSO58 User Manual

Commands listed in alphabetical order
Examples
DISplay:WAVEV
iew1:CURSor:CURSOR1:HBArs:AP OSition 3.0e0
sets the
cursor position to 3 V.
DISplay:WAVE
View1:CURSor:CURSOR1:HBArs :APOSition?
might
return
:DISPLAY:WAVEVIEW1:CURSOR:C URSOR1:HBARS:APOSITION
2.9303448275862
indicating the cursor position is 2.93 V.
DISplay:WA
VEView<x>:CURSor:CURSOR<x>:HBArs:AUNIts? (Query Only)
This command queries the cursor A vertical units of the specified cursor in the
specified waveview.
NOTE.
WAV
EView<x>
is the specified waveview and must be WAVEView1 .
Cursor<x> is the specified cursor and must be CURSOR1 .
Group
Cursor
Syntax
DISplay:WAVEView<x>:CURSor :CURSOR<x>:HBArs:AUNIts?
Arguments
<QString> is the cursor A vertical units of the specified cursor in the specified
waveview.
Examples
DISplay:WAVEView1:CURSor:C URSOR1:HBArs:AUNIts? might return
:DISPLAY:WAVEVIEW1:CURSOR: CURSOR1:HBARS:AUNITS "V" indicating
the
AUNITS are set to Volts.
DISplay:WAVEView<x>:CURSor:CURSOR<x>:HBArs:BPOSition
Queries the HBARs vertical B position of the specified cursor in the specified
waveview.
NOTE.
WAVEView<x > is the specified waveview and must be WAVEView1 .
Cursor<x> is the specified cursor and must be CURSOR1 .
Group
Cursor
Syntax
DISplay:WAVEView<x>:CURSor :CURSOR<x>:HBArs:BPOSition <NR3>
DISplay:WAVEView<x>:CURSor :CURSOR<x>:HBArs:BPOSition?
MSO54, MSO56, MSO58, MSO58LP Programmer 2-291
