Tektronix MSO58 User Manual

Commands listed in alphabetical order
Examples
DISPLAY:WAVEV
IEW1:CURSOR:CURSOR1:SCREEN:A XPOSITION 15.0E-3
sets the x position of the specified screen cursor in the specified waveview to 15
mV.
DISPLAY:WAVEVIEW1:CURSOR: CURSOR1:SCREEN:AXPOSITION? might
return :
DISPLAY:WAVEVIEW1:CURSOR:CU RSOR1:SCREEN:AXPOSITION
-64.0000E-03 indicating that x position of the specified screen cursor in the
specified waveview is set to -64 mV.
DISplay:WAVEView<x>:CURSor:CURSOR<x>:SCREEN:BYPOSition
This comm
and sets or queries the vertical cursor B position of the specified cursor
in the specified waveview.
NOTE.
WAVEView<x> is the specified waveview and must be WAVEView1 .
Cursor<x> is the specified cursor and must be CURSOR1 .
Group
Cursor
Syntax
DISplay:WAVEView<x>:CURSo r:CURSOR<x>:SCREEN:BYPOSition <NR3>
DISplay:WAVEView<x>:CURSo r:CURSOR<x>:SCREEN:BYPOSition?
Arguments
<NR3> the vertical cursor B position of the specified cursor in the specified
waveview.
Examples
DISPLAY:WAVEVIEW1:CURSOR: CURSOR1:SCREEN:BYPOSITION 25.0E-3
sets the y position of the screen cursor of waveview1 to 25 mV.
DISPLAY:WAVEVIEW1:CURSOR: CURSOR1:SCREEN:BYPOSITION? might
return
:DISPLAY:WAVEVIEW1:CURSOR: CURSOR1:SCREEN:BYPOSITION
-53.0000E-03
indicating that y position of the specified screen cursor of the
specified waveview is set to -53 mV.
DISplay:WAVEView<x>:CURSor:CURSOR<x>:SPLITMODE
This command sets or queries whether both cursors have the same or different
sources.
NOTE.
WAVEView<x> is the specified waveview and must be WAVEView1 .
Cursor<x> is the specified cursor and must be CURSOR1 .
2-296 MSO54, MSO56, MSO58, MSO58LP Programmer
