Tektronix MSO58 User Manual

Commands listed in alphabetical order
DISplay:REFF
FTView<x>:CURSor:WAVEform:BPOSition
Sets or returns the waveform cursor B position in the specified plot view.
NOTE. In case of an XY plot, this command has no effect when used to set the
value. In th
e case of a bathtub plot, this command has no effect. Queries re turn
invalid values. For all other plots, this command sets or queries the cursor
B horizontal position.
Group
Cursor
Syntax
DISplay:REFFFTView<x>:CURS or:WAVEform:BPOSition <NR3>
DISplay:REFFFTView<x>:CURS or:WAVEform:BPOSition?
Arguments
<NR3> is the waveform cursor B position in the specified plot view.
Examples
DISplay:REFFFTView5:CURSor :WAVEform:BPOSition 4E+8 sets the
cursor position to 400 MHz.
DISplay:REFFFTView5:CURSor :WAVEform:BPOSition? might
return
:DISPLAY:REFFFTVIEW5:CURSO R:WAVEFORM:BPOSITION
394.3483403001212E+6
indicating the B waveform curosr position is 394.35
MHz.
DISplay:REFFFTView<x>:CURSor:WAVEform:BVPOSition? (Query Only)
This query-only command returns the value of the cursor B vertical position.
Group
Cursor
Syntax
DISplay:REFFFTView<x>:CURS or:WAVEform:BVPOSition?
Examples
DISplay:REFFFTView1:CURSor :WAVEform:BVPOSition? might
return
:DISplay:REFFFTView<x>:CURS or:WAVEform:BVPOSition
-119.866E+0
indicating the cursor vertical position is -119.9 dBm..
DISplay:REFFFTView<x>:GRIDlines
This command sets or returns the grid lines setting o f the plot.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-275
