Commands listed in alphabetical order
Group
Search and Mark
Syntax
SEARCH:SEARCH<x>:TRIGger: A:BUS:ARINC429A:SDI:VALue <QString>
SEARCH:SEARCH<x>:TRIGger: A:BUS:ARINC429A:SDI:VALue?
Arguments
<QString> is the label value.
NOTE. The SDI field i s only present when the selected data field format is DATA
(using
BUS:B<x>:ARIN C429A:DATAFORmat ). Also, the stored QString is reset
to its default value whenever the data field format is changed.
Examples
SEARCH:SEARCH1:TRIGGER:A: BUS:ARINC429A:SDI:VALUE " X0" sets the
value to X0.
SEARCH:SEARCH1:TRIGGER:A: BUS:ARINC429A:SDI:VALUE? might return
"XX", indicating that the value is XX.
SEARCH:SEARCH<x>:TRIGger:A:BUS:ARINC429A:SSM:VALue
This command sets or queries the l
abel when searching on an ARINC429 SSM
field. The search number is specified by x. The search condition must be set
to DATa or LABELANDDATA, and the data format must be set to DATA or
SDIDATA.
Conditions
Requires the SR-AERO Triggering and Analysis application.
Group
Search and Mark
Syntax
SEARCH:SEARCH<x>:TRIGger: A:BUS:ARINC429A:SSM:VALue <QString>
SEARCH:SEARCH<x>:TRIGger: A:BUS:ARINC429A:SSM:VALue?
Arguments
<QString> is the label value.
Examples
SEARCH:SEARCH1:TRIGGER:A: BUS:ARINC429A:SSM:VALUE " X0" sets the
value to X0.
SEARCH:SEARCH1:TRIGGER:A: BUS:ARINC429A:SSM:VALUE? might return
"XX", indicating that the value is XX.
2-636 MSO54, MSO56, MSO58, MSO58LP Programmer
