Commands listed in alphabetical order
SAVEON:IMAGE?
might return :SAVEON:IMAGE 1, indicating that the
oscilloscope will save a screen capture when the specified trigger occurs.
SAVEON:IMAGe:FILEFormat
This command sets or queries the file format to be used for saved image files
when :SAVEON:IMAGe is set to 1.
Group
Save On
Syntax
SAVEON:IMAGe:FILEFormat {PNG|BMP|JPG}
SAVEON:IMAGe:FILEFormat?
Arguments
PNG specifies using PNG format for saved image files.
BMP specifies using BMP format for saved image files.
JPG specifies using JPEG format for saved image files.
When specifying the file name with this command, use the correct file extension
(".png" for PNG format, ".bmp" for BMP format, or ".jpg" for JPEG format). If a
file name or path is specified, the file is expected to be located in a directory
relative to the current working directory (specified by FILESystem:CWD)unless
acompletepathisspecified:
Complete path specification. If the file argument begins with drive designator
(such as C:), then the file name is interpreted as a full path.
Relative path specification. If the file argument begins with "." or ".." or has a
file path separator appearing anywhere other than the first character position,
then the file name is treated as a path that is relative to the current working
directory.
Examples
SAVEON:IMAGE:FILEFORMAT JPG sets the image file format to JPEG.
SAVEON:
IMAGE:FILEFORMAT?
might return :SAVEON:IMAGE:FILEFORMAT
PNG
indicating that the file format is set to PNG.
SAVEON:TRIGger
Sets or queries whe ther to save a file when a trigger occurs. You can define the
trigger using Trigger commands or the oscilloscope user interface.
The trigger will cause the instrument to save an image or a waveform t o a file,
depending on what you specified. For example, if you have set SAVEON:IMAGe
to On, and a trigger event occurs, the instrument will save a screen capture.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-625
