Tektronix MSO58 User Manual

Commands listed in alphabetical order
DISplay:WAVE
View<x>:ZOOM:ZOOM<x>:HORizontal:WINSCALe
This command sets or queries the overview window horizontal scale in the
specified waveview.
NOTE.
WAVEV
iew<x>
is the specified waveview and must be WAVEView1 .
ZOOM<x> is the specified zoom and must be ZOOM1 .
Group
Zoom
Syntax
DISplay:WAVEView<x>:ZOOM:Z OOM<x>:HORizontal:WINSCALe <NR3>
DISplay:WAVEView<x>:ZOOM:Z OOM<x>:HORizontal:WINSCALe?
Arguments
<NR3> is the horizontal scale of the zoom window.
Examples
DISplay:WAVEView1:ZOOM:ZOO M1HORizontal:WINSCALe? might return
:DISPLAY:WAVEVIEW1:ZOOM:ZO OM1:HORIZONTAL:WINSCALE 8 0.0000E-9
indicating that the horizontal scale of the overview window is 80 ns per division.
DISplay:WAVEView<x>:ZOOM:ZOOM<x>:STATe
This command sets or queries the zoom display state of the specified zoom in the
specified waveview. This command is equivalent to pushing the zoom button
on the front panel.
NOTE.
WAVEView<x > is the specified waveview and must be WAVEView1 .
ZOOM<x> is the specified zoom and must be ZOOM1 .
Group
Zoom
Syntax
DISplay:WAVEView<x>:ZOOM:Z OOM<x>:STATe {ON|OFF|<NR1>}
DISplay:WAVEView<x>:ZOOM:Z OOM<x>:STATe?
Arguments
ON turns the specified zoom on.
OFF turns specified zoom off.
<NR1> = 0 disables the specified zoom; any other value enables the specified
zoom.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-313
