Command groups
Digital command group
Use the commands in the Digital Command Group to acquire up to 64 digital
signals and analyze them. Digital channels are only available when a digital
probe is attached to the super channel.
Table 2-24: Digital commands
Command Description
CH<x>_DALL:LABel:COLor Sets or queries the color of the specified digital group label.
CH<x>_DALL:LABel:FONT:BOLD Sets or queries the bold state of the specified digital group.
CH<x>_DALL:LABel:FONT:ITALic Sets or queries the italic state of the specified digital group.
CH<x>_DALL:LABel:FONT:SIZE Sets or queries the font size of the specified digital g roup.
CH<x>_DALL:LABel:FONT:TYPE Sets or queries the font type of the specified digital group, such as Arial or Times
New Roman.
CH<x>_DALL:LABel:FONT:UNDERline Sets or queries the underline state of the specified digital group.
CH<x>_DALL:LABel:NAMe Sets or queries the label of the specified digital group.
CH<x>_D<x>:LABel:COLor Sets or queries the color of the label of the s pecifi ed digital bit.
CH<x>_D<x>:LABel:FONT:BOLD Sets or queries the bold state of the label of the specified digital bit.
CH<x>_D<x>:LABel:FONT:ITALic Sets or queries the italic state of the label of the specified digital bit.
CH<x>_D<x>:LABel:FONT:SIZE Sets or queries the font size of the label of the specified digital bit
CH<x>_D<x>:LABel:FONT:TYPE Sets or queries the font type of the label of the specified digital bit,
CH<x>_D<x>:LABel:FONT:UNDERline Dets or queries the underline state of the label of the specified digital bit.
CH<x>_D<x>:LABel:NAMe Sets or queries the label of the specified digital bit.
REF<x>_DALL:LABel:COLor Sets or queries the color of the specified digital group.
REF<x>_DALL:LABel:FONT:BOLD Sets or queries the bold state of the specified digital group.
REF<x>_DALL:LABel:FONT:ITALic Sets or queries the italic state of the specified digital group.
REF<x>_DALL:LABel:FONT:SIZE Sets or queries the font size of the specified digital group.
REF<x>_DALL:LABel:FONT:TYPE Sets or queries the font type of the specified digital g roup.
REF<x>_DALL:LABel:FONT:UNDERline Sets or queries the underline state of the specified digital group.
REF<x>_DALL:LABel:NAMe
Sets or queries the label of the specified digital group.
REF<x>_DALL:LABel:XPOS Sets or queries the x-position of the label of the specified digital g roup.
REF<x>_DALL:LABel:YPOS Sets or queries the y-position of the label of the specified digital g roup.
REF<x>_D<x>:LABel:COLor Sets or queries the color of the label of the specified digital channel.
REF<x>_D<x>:LABel:FONT:BOLD Sets or queries the bold state of the label of the specified digital bit.
REF<x>_D<x>:LABel:FONT:ITALic Sets or queries the italic state of the label of the specified digital bit.
REF<x>_D<x>:LABel:FONT:SIZE Sets or queries the font size of the label of the specified digital bit.
REF<x>_D<x>:LABel:FONT:TYPE Sets or queries the font type of the label of the specified digital bit.
REF<x>_D<x>:LABel:FONT:UNDERline Sets or queries the underline state of the label of the specified digital bit.
REF<x>_D<x>:LABel:NAMe
Sets or queries the label of the specified digital bit.
REF<x>_D<x>:LABel:XPOS Sets or queries the x-position of the label of the specified digital bit.
2-26 MSO54, MSO56, MSO58, MSO58LP Programmer
