Command groups
Search and Mar
k command group
Use search and mark commands to seek out and identify information in waveform
records that warrant further investigation.
Table 2-37:
Search and Mark commands
Command
Descriptio
n
SEARCH:ADDNew Adds the specified search.
SEARCH:DELete Deletes the specified search.
SEARCH:LIST? Lists all currently defined searches.
SEARCH:SEARCH<x>:COPy Copies the search criteria to or from the trigger.
SEARCH:SEARCH<x>:NAVigate Sets the navigation action for search marks.
SEARCH:SEARCH<x>:TOTAL? Queries the total number of found search marks for this search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ARINC429A:CONDition
Specifies a field or condition for an ARINC429 bus to search on.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ARINC
429A:ERRTYPe
Sets or queries the error type when searching on an ARINC429 bus signal.
SEAR
CH:SEARCH<x>:TR IGger:A:BUS:
ARINC429A:LABel:QUALifier
Sets
or queries the qualifier to be used when searching on label data for an
ARINC429 bus signal.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ARINC429A:LABel:VALue
Sets or queries the low value when searching on an ARINC429 label field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ARI
NC429A:LABel:HIVALue
Sets or queries the high value when searching on an ARINC429 label field.
SE
ARCH:SEARCH<x>:TRIGger:A:BUS:
ARINC429A:SDI:VALue
Se
ts or queries the when searching on an ARINC429 SDI field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ARINC429A:SSM:VALue
Sets or queries the when searching on an ARINC429 SSM field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ARINC429A:DATa:QUALifier
Sets or queries the qualifier to be used when searching on data in the DATA field
for an ARINC429 bus signal.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ARINC429A:DATa:VALue
Sets or queries the low value when searching on an ARINC429 data field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ARINC429A:DATa :HIVALue
Sets or queries the high value when searching on an A RINC429 data field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
AUDio:CONDition
Sets or queries the condition (word select / frame sync, or matching data) to be
used when searching on an audio bus signal.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
AUDio:DATa:HITDMVALue
Sets or queries the binary data s tring for the high data word to be used when
searching on an TDM audio bus signal.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
AUDio:DATa:HIVALue
Sets or queries the binary data s tring for the high data word to be used when
searching on an audio bus signal.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
AUDio:DATa:OFFSet
Sets or queries the data offset value (TDM channel) to be used when searching on
a TDM type audio bus signal.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
AUDio:DATa:QUALifier
Sets or queries the qualifier to be used when searching on an audio bus signal.
