Commands listed in alphabetical order
Arguments
SOW specifies a s
earch for the first bit of a word.
LABel specifies a search for a matching la bel.
DATa specifies a search for matching packet data fields.
LABELANDDATA specifies a search for a matching label and matching packet
data field(s).
EOW specifies a search for the 32nd bit of a word.
ERRor specifiesasearchforaspecified error condition.
NOTE. The type of error searched for is specified by
SEARCH:SEA RCH<x>:TRIGger:A:BUS:ARINC42 9A:ERRTYPe
.
Examples
SEARCH:SEARCH1:TRIGGER:A:B US:ARINC429A:CONDITION DA TA specifies
finding packets that contain matching data field(s).
SEARCH:SEARCH1:TRIGGER:A:B US:ARINC429A:CONDITION? might return
SOW, indicating that the bus is being searched for the first bit of each word in
the packet.
SEARCH:SEARCH<x>:TRIGger:A:BUS:ARINC429A:DATa:HIVALue
This command sets or queries the high value when searching on an ARINC429
data field. The search number is specified by x. The search condition must be
settoDATaorLABELANDDATA,andthedataqualifier must be INrange or
OUTrange.
Conditions
Requires the SR-AERO Triggering and Analysis application.
Group
Search and Mark
Syntax
SEARCH:SEARCH<x>:TRIGger:A :BUS:ARINC429A:DATa:HIVALue
<QString>
SEARCH:SEARCH<x>:TRIGger:A :BUS:ARINC429A:DATa:HIVALue?
Arguments
<QString> is the label value.
Examples
SEARCH:SEARCH1:TRIGGER:A:B US:ARINC429A:DATA:HIVALUE
"XXXXXXXXXXXXXXX1000"
sets the value to XXXXXXXXX XXXXXX1000.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-631
