Tektronix MSO58 - DISplay:WAVEView<x>:REF:REF<x>:VERTical:POSition; DISplay:WAVEView<x>:REF:REF<x>:VERTical:SCAle

Commands listed in alphabetical order
Syntax
DISplay:WAVEV
iew<x>:REF:REF<x>:STATE {<NR1>|OFF|ON }
DISplay:WAVEView<x>:REF:R EF<x>:STATE?
Arguments
<NR1> = 0 disables the specifi ed reference in the specified waveview; any other
value turns this feature on.
OFF disables the specified reference in the specified waveview.
ON enables the specified reference in the specified waveview.
Examples
DISplay:WAVEView1:REF:REF 1:STATE OFF disables the specified reference
in the specified waveview.
DISplay:WAVEView1:REF:REF 1:STATE? might return
:DISPLAY:WAVEVIEW1:REF:RE F1:STATE 1 indicating the specified
reference in the specified waveview is on.
DISplay:WAVEView<x>:REF:REF<x>:VERTical:POSition
This command sets or queries the vertical position in divisions of the s pecified
reference in the specified waveview.
NOTE.
WAVEView<x> is the specified waveview and must be WAVEView1 .
Group
Display Control
Syntax
DISplay:WAVEView<x>:REF:R EF<x>:VERTical:POSition < NR3>
DISplay:WAVEView<x>:REF:R EF<x>:VERTical:POSition?
Arguments
<NR3> is the vertical position in divisions.
Examples
DISplay:WAVEView1:REF:REF 1:VERTical:POSition -2.5e 0 sets the
position to -2.5 divisions.
DISplay:WAVEView1:REF:REF 1:VERTical:POSition? might return
:DISPLAY:WAVEVIEW1:REF:RE F1:VERTICAL:POSITION -2.6 400
indicating the position is set to -2.64 divisions.
DISplay:WAVEView<x>:REF:REF<x>:VERTical:SCAle
This command sets or queries the vertical scale of the specified reference in volts
per div within the s pecified waveview.
2-308 MSO54, MSO56, MSO58, MSO58LP Programmer
