Commands listed in alphabetical order

Syntax

CH<x>:PRObe:G

AIN?

Examples

CH2:PROBE:GAIN? might return :CH2:PR OBE:GAIN 100.0000E-3, indicating

that the attached 10X p robe delivers 0.1 V to the Channel 2 BNC for every 1.0 V

applied to the probe input.

CH<x>:PRObe:ID? (Query Only)

This query-only command returns the type and serial number of the probe that is

attached to the speciﬁed channel. The channel is speciﬁed by x.

Group

Vertical

Syntax

CH<x>:PRObe:ID?

Examples

CH2:PROBE:ID? might return :CH2:PROBE:ID:TYPE "10X";SERNUMBE R

"N/A"

, indicating that a passive 10X probe of unknown serial number is attached

to Channel 2.

CH<x>:PRObe:ID:SERnumber? (Query Only)

This query-only command returns the serial number of the probe that is attached

to the speciﬁed channel. The channel is speciﬁed by x.

NOTE. For Level 0 and 1 probes, the serial number will be “N/A”.

Group

Vertical

Syntax

CH<x>:PRObe:ID:SERnumber?

Examples

CH1:PROBE:ID:SERNUMBER? might r eturn :CH1:PROBE:ID:SERNU MBER

"B010289"

, indicating that the serial number of the probe attached to Channel 1

is B010289.

CH<x>:PRObe:ID:TYPe? (Query Only)

This query-only command returns the type of probe that is attached to the

speciﬁed channel. The channel is speciﬁed by x.

2-198 MSO54, MSO56, MSO58, MSO58LP Programmer
