Commands listed in alphabetical order
Returns
Returns the cur
sor parameters for the specified waveview.
Examples
DISplay:WAVEView1:CURSor? might return
:
DISPLAY:WAVEVIEW1:CURSOR:CURSOR:WAVEFORM:BPOSITION
5.0E-6;APOSITION
-5.0E-6;:DISPLAY:WAVEVIEW1:CURSOR:CURSOR:BSOURCE
AU TO;HBARS:BPOSITION 9.91E+37;BUNITS
"V";AUNITS "V";APOSITION 9.91E+37;DELTA
9.91E+37;:DISPLAY:WAVEVIEW1:CURSOR:CURSOR:VBA
RS:BPOSITION 5.0E-6;APOSITION -5.0E-6;UNITS "s";DELTA
10.0E-6;ALTERNATEB "???? ????";ALTERNATEA "????
????";:DISPLAY:WAV EVIEW1:CURSOR:CURSOR:STAT E
1;FUNCTION WAVEFORM;SCREEN:AYPOSITION
-2.0E-3;BXPOSITION -5.0E-6;BY POSITION -2.0E-3;AXPOSITIO N
-5.0E-6;:DISPLAY:WAVEVIEW1:CURSOR:CURSOR:MODE
INDEPENDENT;ASOURCE AUTO;DDT
9.91E+37;ONEOVERDELTATVALUE 100.0E+3;SPLITM ODE
SAME;LINESTYLE SOLID.
DISplay:WAVEView<x>:CURSor:CURSOR<x>? (Query Only)
This query returns the cursor parameters for the specified cursor in the spe cified
waveview.
NOTE.
WAVEView<x > is the specified waveview and must be WAVEView1 .
Cursor<x> is the specified cursor and must be CURSOR1 .
Group
Cursor
Syntax
DISplay:WAVEView<x>:CURSor :CURSOR<x>?
Returns
Returns the cursor parameters for the specified cursor in the specified waveview.
Examples
DISplay:WAVEView1:CURSor:CURSOR1? might return
:DISPLAY:WAVEVIEW1:CURSOR:CURSOR:WAVEFORM:BPOSITION
5.0E-6;APOSITION
-5.0E-6;:DISPLAY:WAVEVIEW1:CURSOR:CURSOR:BSOURCE
AU TO;HBARS:BPOSITION 9.91E+37;BUNITS
"V";AUNITS "V";APOSITION 9.91E+37;DELTA
9.91E+37;:DISPLAY:WAVEVIEW1:CURSOR:CURSOR:VBA
RS:BPOSITION 5.0E-6;APOSITION -5.0E-6;UNITS "s";DELTA
10.0E-6;ALTERNATEB "???? ????";ALTERNATEA
MSO54, MSO56, MSO58, MSO58LP Programmer 2-287
