Commands listed in alphabetical order

Examples

CH2:SCAle 200E

-3

sets the scale to 200 mV per division.

CH2:SCAle? might return :CH2:SCALE 500.0 000E-3 indicating the vertical

scaleforthes

peciﬁed channel is 500 mV per division.

CH<x>:SCALERATio

This command sets or returns the scale ration for the speciﬁed analog channel.

Group

Horizontal

Syntax

CH<x>:SCALERATio <NR2>

CH<x>:SCALERATio?

Arguments

<NR2> is the scale ration for the speciﬁed analog cha nnel.

Examples

CH2:SCALERATio 2.0 sets the scale ratio to 2.0.

CH2:SCALERATio? might return :CH2:SCALERATIO 1.0000 indicating the

scale ratio is 1.0.

CH<x>:TERmination

This command sets or queries the vertical termination for the speciﬁed analog

channel. The channel is speciﬁed by x.

NOTE. Theavailableargument

s depend on the instrument model and the attached

accessories.

Group

Vertical

Syntax

CH<x>:TERmination <NR3>

CH<x>:TERmination?

Arguments

<NR3> speciﬁes the channel input resistance, which can be speciﬁed as 50 Ω or

1,000,000 Ω.

2-204 MSO54, MSO56, MSO58, MSO58LP Programmer
