Tektronix MSO58 - Trigger command group

Command groups
Trigger command group
Use the commands in the Trigger Command Group to control all aspects of
triggering for the instrument.
There are two triggers: A and B. Where appropriate, the command set has parallel
constructions for each trigger.
You c an set the A or B triggers to edge mode. Edge triggering lets you display
a waveform at or near the point where the signal passes through a voltage level
of your choosing.
You can also set A or B triggers to pulse or logic modes. With pulse triggering,
the instrument triggers whenever it detects a pulse of a certain width or height.
Logic triggering lets you logically combine the signals on one or m ore channels.
The instrument then triggers when it detects a certain combination of signal levels.
The trigger types of Pulse Width, Timeout, Runt, Window, and Rise/Fall Time can
be further qualified by a logic pattern. This is referred to as logic qualification.
Table 2-40: Trigger commands
Command
Description
TRIGger Forces a trigger event to occur or returns current trigger parameters for the
instrument.
TRIGger:{A|B}:BUS:B<x>:ARINC429A:
CONDition
Specifies a field or condition for an ARINC429 bus to trigger on.
TRIGger:{A|B}:BUS:B<x>:ARINC429A:
ERRTYPe
Sets or queries the error type w hen triggering on an ARINC429 bus signal.
TRIGger:{A|B}:BUS:B<x>:ARINC429A:
LABel:QUALifier
Sets or queries the qualifier to be used when triggering on label data for an
ARINC429 bus signal.
TRIGger:{A|B}:BUS:B<x>:ARINC429A:
LABel:VALue
Sets or queries the low value when triggering on an ARINC429 label field.
TRIGger:{A|B}:BUS:B<x>:ARINC429A:
LABel:HIVALue
Sets or queries the high value w hen triggering on an A RINC429 label field.
TRIGger:{A|B}:BUS:B<x>:ARINC429A:SDI:
VALue
sSets or queries the when triggering on an ARINC429 SDI field.
TRIGger:{A|B}:BUS:B<x>:ARINC429A:SSM:
VALue
Sets or queries the when triggering on an ARINC429 SSM field.
TRIGger:{A|B}:BUS:B<x>:ARINC429A:DATa:
QUALifier
Sets or queries the qualifier to be used when triggering on data in the DATA field
for an ARINC429 bus signal.
TRIGger:{A|B}:BUS:B<x>:ARINC429A:DATa:
VALue
Sets or queries the low value when triggering on an A RINC429 data field.
TRIGger:{A|B}:BUS:B<x>:ARINC429A:DATa:
HIVALue
Sets or queries the high value when trigger on an ARINC429 data field.
TRIGger:{A|B}:BUS:B<x>:AUDio:CONDition Sets the condition (word select, start of frame, or matching data) to be used when
triggering on an audio bus signal.
TRIGger:{A|B}:BUS:B<x>:AUDio:DATa:
HIVALue
Sets the upper word value to be used when triggering on an audio bus signal.
