Command groups
Table 2-40: Trigger commands (cont.)
Command
Description
TRIGger:{A|B}:BUS:B<x>:AUDio:DATa:
HITDMVALue
Sets or queries the binary data string for the high data word to be used when
triggering on an TDM audio bus signal.
TRIGger:{A|B}:BUS:B<x>:AUDio:DATa:
OFFSet
Sets the data offset value to be used when triggering on an audio bus signal.
TRIGger:{A|B}:BUS:B<x>:AUDio:DATa:
QUALifier
Sets the qualifier (<, >, =, <=, >=, not =, in range, out of range) to be used when
triggering on an audio bus signal.
TRIGger:{A|B}:BUS:B<x>:AUDio:DATa:
TDMVALue
Sets or queries the binary data string for the single or low data word to be used when
triggering on an TDM audio bus signal.
TRIGger:{A|B}:BUS:B<x>:AUDio:DATa:
VALue
Sets the lower word value to be used when triggering on an audio bus signal.
TRIGger:{A|B}:BUS:B<x>:AUDio:DATa:
WORD
Sets the alignment of the data (left, right or either) to be used to trigger on an
audio bus signal.
TRIGger:{A|B}:BUS:B <x>:CAN:CONDition Sets the condition (start of frame, frame type, identifier, m atching data, EOF, missing
ACK field, bit-stuffing error) to be used when triggering on a CAN bus signal.
TRIGger:{A|B}:BUS:B <x>:CAN:DATa:
DIRection
Sets the data direction (read, write or “nocare”) to be used to search on a CAN
bus signal.
TRIGger:{A|B}:BUS:B <x>:CAN:DATa:
OFFSet
Sets or queries the data offset value, in bytes, to use when triggering on the CAN
data field.
TRIGger:{A|B}:BUS:B <x>:CAN:DATa:
QUALifier
Sets the qualifier (<, >, =, not =, <=, >=) to be used when triggering on a CAN bus
signal.
TRIGger:{A|B}:BUS:B <x>:CAN:DATa:SIZe Sets the length of the data string, in bytes, to be used when triggering on a CAN
bus signal.
TRIGger:{A|B}:BUS:B<x>:CAN:DATa:VALue Sets the binary data value to be used when triggering on a CAN bus signal.
TRIGger:{A|B}:BUS:B<x>:CAN:ERRType Sets or queries the type of error condition for a CAN bus to triggering on.
TRIGger:{A|B}:BUS:B <x >:CAN :F D:BR SBit Sets or queries the value of the bit rate switch bit (BRS bit) for a CAN bus to
triggering on.
TRIGger:{A|B}:BUS:B <x>:CAN:FD:ESIBit Sets or queries the value of the error state indicator bit (ESI bit) for a CAN bus to
triggering on.
TRIGger:{A|B}:BUS:B<x>:CAN:FRAMEtype Sets the frame type (data, remote, error or overload) to be used when triggering on
a CAN bus signal.
TRIGger:{A|B}:BUS:B <x >:CAN:IDentifier:
MODe
Sets the addressing mode (standard or extended format) to be used when triggering
on a CAN bus signal.
TRIGger:{A|B}:BUS:B <x >:CAN:IDentifier:
VALue
Sets the binary address value to be used when triggering on a CAN bus signal.
TRIGger:{A|B}:BUS:B<x>:ETHERnet:
CONDition
Specifies a field or condition within an Ethernet frame to trigger on.
TRIGger:{A|B}:BUS:B<x>:ETHERnet:DATa:
HIVALue
When the Ethernet trigger condition is set to DATa, and the qualifier is set to either
INrange orOUTrange, this command specifies the upper data value of the r ange.
TRIGger:{A|B}:BUS:B<x>:ETHERnet:DATa:
OFFSet
When the Ethernet trigger condition is set to DATa, this c ommand specifies where i n
the data field to look for the data trigger value.
TRIGger:{A|B}:BUS:B<x>:ETHERnet:DATa:
QUALifier
Sets or queries the qualifier to be used when triggering on an Ethernet bus signal.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-77
