Tektronix MSO58

Commands listed in alphabetical order
DISplay:WAVE
View<x>:CH<x>:VERTical:POSition
Sets or queries the vertical position of the specified channel in the specified
waveview in divisions. 0.0 divisions is center, 5.0 top of the window, and -5.0 the
bottom of the
window.
NOTE.
WAVEView<x> is the specified waveview and must be WAVEView1 .
Group
Display Co
ntrol
Syntax
DISplay:WAVEView<x>:CH<x> :VERTical:POSition <NR3>
DISplay:WAVEView<x>:CH<x> :VERTical:POSition?
Arguments
<NR3> is the vertical position in divisions. 0.0 divisions is center, 5.0 top of the
window, and -5.0 the bottom of the window.
Examples
DISplay:WAVEView1:CH1:VER Tical:POSition 1.0e0 sets the position
to 1 division.
DISplay:WAVEView1:CH1:VER Tical:POSition? might return
:DISPLAY:WAVEVIEW1:CH1:VE RTICAL:POSITION -3.4400 indicating the
channel 1 vertical position is -3.44 divisions.
DISplay:WAVEView<x>:CH<x>:VERTical:SCAle
Sets or queries the vertical scale of the specified channel in volts per division
within the specified waveview.
NOTE.
WAVEView<x> is the specified waveview and must be WAVEView1 .
Group
Display Control
Syntax
DISplay:WAVEView<x>:CH<x> :VERTical:SCAle <NR3>
DISplay:WAVEView<x>:CH<x> :VERTical:SCAle?
Arguments
<NR3> is the vertical scale of the specified channel.
Examples
DISplay:WAVEView1:CH1:VER Tical:SCAle 2.0e2 sets the vertical scale to
200 mV per division.
2-284 MSO54, MSO56, MSO58, MSO58LP Programmer
