Commands listed in alphabetical order
Table 2-46: Waveform Suffixes (cont.)
Field Description Examples
Record Length
A string containing the number of waveform
points available in the entire record. The
numeric portion is given as an integer.
"500 points"
"500000 points"
Acquisition Mode A string describing the mode used to acquire
the waveform.
"Sample mode"
"Pk Detect mode"
"Hi Res mode"
"Envelope mode"
"Average mode"
Examples
WFMOUTPRE:WFID? might return :WFMOUTPRE:WFID "Ch1, DC
coupling,100.0mVolts/div,5 00.0µs/div,500 points, Hi Res
mode"
.
WFMOutpre:XINcr? (Query Only)
This query-only command returns the horizontal point spacing in units of
WFMOutpre:XUNit for the waveform specified by the DATa:SOUrce command.
This value corresponds to the sampling interval.
An error is reported if the DATa:SOUrce waveform does not exist.
Group
Waveform Transfer
Syntax
WFMOutpre:XINcr?
Related Commands
DATa:SOUrce, WFMOutpre:XUNit?
Examples
WFMOUTPRE:XINCR? might return :WFMOUTPRE:XINCR 10.0000E-6,
indicating that the horizontal sampling interval is 10 µs/point (500 µs/div).
WFMOutpre:XUNit? (Query Only)
This query-only command returns the horizontal units for the waveform specified
by the DATa:SOUrce command.
An error is reported if the DATa:SOUrce waveform does not exist.
Group
Waveform Transfer
MSO54, MSO56, MSO58, MSO58LP Programmer 2-897
