Tektronix MSO58

Command groups
Table 2-25: Display control commands (cont.)
Command
Description
DISplay:INTENSITy:B ACK Light:AUTODim:
ENAble
Sets or queries the state of the display auto-dim feature.
DISplay:INTENSITy:B ACK Light:AUTODim:
TIMe
Sets or queries the amount of time, in m inutes, to wait for no user interface a ctivity
before automatically dimming the display.
DISplay:MATHFFTView<x>:AUTOScale Sets or returns the enabled state of autoscale for plots.
DISplay:MATHFFTView<x>:GRIDlines Sets or queries the grid lines setting of the plot.
DISplay:MATHFFTView<x>:MATH:MAT H<x>:
STATE
Sets or queries the state of the specified math waveform in the specified waveview.
DISplay:MATHFFTView<x>:XAXIS:SCALE Sets or queries the x-axis scale s etting for FFT Math waveforms.
DISplay:MATHFFTView<x>:YAXIS:SCALE Sets or queries the vertical scale setting for FFT Maths.
DISplay:PERSistence Sets or queries display persistence setting.
DISplay:PERSistence:RESET Clears the persistence data.
DISplay:PLOTView<x>:AUTOScale Sets or queries the enabled state o f autoscale for plots.
DISplay:PLOTView<x>:GRIDlines Sets or queries the Grid lines setting of the specified plot.
DISPLAY:PLOTVIEW<x>:XAXIS:SCALE Sets or queries the horizontal scale setting for applicable plot.
DISPLAY:PLOTVIEW<x>:YAXIS:SCALE Sets or queries the vertical scale setting for applicable plots.
DISplay:REFFFTView<x>:AUTOScale Sets or queries the enabled state of auto-scale for plots.
DISplay:REFFFTView<x>:GRIDlines Sets or returns the grid lines setting of the plot.
DISplay:REFFFTView<x>:REF:REF<x>:
STATE
Sets or queries the state of the specified reference waveform in the specified
waveview.
DISplay:REFFFTView<x>:XAXIS:SCALE Sets or queries the x-axis scale setting for REFFFT.
DISplay:SELect:BUS Sets or queries the overall selected bus.
DISplay:SELect:MATH Sets or queries the overall selected math.
DISplay:SELect:REFerence Sets or queries the overall selected reference waveform.
DISplay:SELect:SOUrce Sets or queries the overall selected source.
DISplay:SELect:VIEW Sets or queries the selected view.
DISplay:SELect:WAVEView<x>:SOUrce Sets o r queries the selected source in the given waveview.
DISplay:VARpersist Sets or queries the persistence decay time.
DISplay:WAVEView<x>:BUS:B<x>:STATE Sets or queries the state of the specified bus in the specified waveview.
DISplay:WAVEView<x>:BUS:B<x>:VERTical:
POSition
Sets or queries the vertical position of the specified bus in the specified waveview.
DISplay:WAVEView<x>:CH<x>:STATE Sets or queries the state of the specified channel in the specified waveview.
DISplay:WAVEView<x>:CH<x>:VERTical:
POSition
Sets or queries the vertical position f the specified channel in the specified waveview
in divisions.
DISplay:WAVEView<x>:CH<x>:VERTical:
SCAle
Sets or queries the vertical scale of the specified channel in volts per division within
the specified waveview.
DISplay:WAVEView<x>:CH<x>_DALL:STATE Sets or queries the display s tate of the specified digital channels in the specified
waveview.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-29
