Command groups
Table 2-30: Math commands (cont.)
Command
Description
MATH:MATH<x>:FUNCtion Sets or queries the basic math arithmetic function.
MATH:MATH<x>:LABel:COLor Sets or queries color of the specified math's label.
MATH:MATH<x>:LABel:FONT:BOLD Sets or queries bold state of the specified math label.
MATH:MATH<x>:LABel:FONT:ITALic Sets or queries italic state of the specified math label.
MATH:MATH<x>:LABel:FONT:SIZE Sets or queries font size of the specified math label.
MATH:MATH<x>:LABel:FONT:TYPE Sets or queries font type of the specified math label.
MATH:MATH<x>:LABel:FONT:UNDERline Sets or queries the underline state of the specified math label.
MATH:MATH<x>:LABel:XPOS Sets or queries the X screen offset where the math waveform label is displayed.
MATH:MATH<x>:LABel:YPOS Sets or queries the Y screen offset where the math waveform label is displayed.
MATH:M ATH<x>:DEFine
Defines new waveforms using mathematical expressions.
MATH:M ATH<x>:GATing Specifies or returns the gating setting.
MATH:MATH<x>:LABel:NAMe
Sets or queries the label string.
MATH:M ATH<x>:SOUrce<x> Sets or queries the specified math source.
MATH:M ATH<x>:SPECTral:HORZ Sets or queries the horizontal display scale of the spectral math waveform.
MATH:M ATH<x>:SPECTral:MAG Sets or queries the units of the SpectralMag function in the specified math definition
string.
MATH:MATH<x>:SPECTral:PHASE Sets or queries the units of a SpectralPhase function in the specified math definition
string.
MATH:MATH<x>:SPECTral:SOUrce Sets or queries the specified spectral math source.
MATH:MATH<x>:SPECTral:SUPPress Sets or queries whether suppression threshold for the specified math waveform is
enabled.
MATH:MATH<x>:SPECTral:SUPPress:VALue Sets or queries in volts the value of suppression threshold of the specified math
waveform.
MATH:M ATH<x>:SPECTral:TYPE Sets or queries the FFT type selected for spectral analysis.
MATH:M ATH<x>:SPECTral:UNWRap Sets or queries whether phase unwrap of the spectral analyzer output data is
enabled.
MATH:M ATH<x>:SPECTral:UNWRap:
DEGrees
Sets or queries in degrees the value of unwrap phase.
MATH:MATH<x>:SPECTral:WINdow Sets or queries the window function used to multiply the spectral analyzer input
data for the specified math waveform.
MATH:M ATH<x>:TYPe
Sets or queries the math type.
MATH:MATH<x>:VUNIT
Sets or queries the math custom vertical units.
2-38 MSO54, MSO56, MSO58, MSO58LP Programmer
