Command groups
Table 2-32: Miscellaneous commands (cont.)
Command
Description
PAUSe Causes the i nterface to pause the specified number of seconds before processing
any other commands.
REM
Specifies a comment which is ignored by the i nstrument.
ROSc:SOUrce Selects or queries the selected source for the time base reference oscillator.
ROSc:STATE? Returns whether the time base reference oscillator is locked.
SET? Returns a listing of instrument settings.
SOCKETServer:ENAble Enables or disables the socket server which supports a telnet or other TCPIP socket
connection to send commands and queries to the instrument.
SOCKETServer:PORT Sets the TCPIP port for the s ocket server connection.
SOCKETServer:PROTOCol Sets or queries the protocol for the socket server.
TEKSecure Initializes both waveform and setup memories.
TIMe? Queries the time displayed by the instrument.
TIMe:ZONe Sets the time zone to the one specified.
TIMe:ZONe:UTCDELTa Sets or queries the time zone using the difference between the desired time zone
and UTC.
TOTaluptime? Returns the total number of hours the oscilloscope has been turned on since the NV
memory was last programmed.
TOUCHSCReen:STATe Sets or queries the enabled state of the touch screen.
*TRG Performs the group execute trigger (GET).
*TST? Tests the interface and returns status.
UNDO Reverts the scope settings to a state before the previous command or user interface
action.
UNLock
Unlocks front panel.
USBDevice:CONFigure Used to configure the rear USB port to be off or enabled as a USBTMC device.
VERBose
Sets or queries the verbose state.
2-54 MSO54, MSO56, MSO58, MSO58LP Programmer
