Appendix D: Waveform Transfer (WFMOutpre and CURVe Query) Examples
NOTE. You can al
so use the
WAVFrm?
query, which concatenates the
WFMOutpre?
and
CURVe?
queries.
WFMOutpre? Query results
Explanation
WFMOUTPRE:B
YT_NR 8
This value specifies the number of bytes per data point in the waveform data. To change
this value automatically, use the WFMOutpre:BYT_Nr command. Note that changing this
value autom
atically changes the
BIT_NR value accordingly. (This value can also be set
using the DATa:WIDth command.)
BIT_NR 64
This value specifies the number of bits per data point in the waveform data. To change this
value, use the WFMOutpre:B IT_Nr command. Note that changing this value automatically
changes th
e
BYT_NR value accordingly.
ENCDG ASCII
This valu
e specifies the encoding of the waveform data. To change this value (the
other possibility is BINARY), use the WFMOutpre:E NCdg command. (This value can
also be set using the DATa:ENCdg command, which provides the ability to set the
WFMOutpr
e:ENCdg, WFMOutpre:BN_ Fmt,
: and WFMOutpre:BYT_Or values
using a single command.)
BN_FMT R
I
This value specifi es the binary format, which in this case is RI (signed integer). To change
this value (the other possibility is RP or positive integer), use the WFMOutpre:BN_Fmt
command
. Note: this field is not applicable for ASCii encoding.
BYT_OR MSB
This va
lue specifies the byte order for the BINARY encoding, which in this case is MSB
(most significant byte first, also known as IBM format). To change this value to LSB, use the
WFMOutpre:BYT_Or command. Note: this field is not applicable for ASCii encoding.
WFID "Digital, unknown
coupling, 100.0us/div,
10000 points, Digital
mode"
This quoted string represents information about the source waveform that would be returned
by a.
W
FMOutpre:WFId?
query. It cannot be changed.
NR_PT 25
This value indicates the number of data points in the waveform record to be transferred
using the CURVE? query. (If you would like to determine only this value, use the
WFMOutpre:NR_Pt? query.) Note: this value is typically equal to the full record length,
but you also have the option to transfer only a portion of the record length by using the
DATa:STARt and DATa:STOP commands.
PT_FMT Y
This value indicates the format of the data points in the waveform record. In this case,
the value represents YT format. This is query only – the returned values can be Y for YT
format or E NV for envelope format (min/max pairs). (If you would like to determine only this
value, use the WFMOutpre:PT_Fmt? query.)
PT_ORDER LINEAR
This value is always LINear.
X
UNIT "s"
This value indicates the units of the x-axis of the waveform record. This is determined by the
horizontal settings for the waveform source. Typically, this value is “s”, representing seconds.
When using the math waveform as a source, the value can be “s” or “Hz”. This is query only.
(If you would like to determine only this value, use the WFMOutpre:XUNit? query.)
XINCR 100.0000E-9
This value indicates the time, in seconds, or frequency, in hertz, between data points in the
waveform record. This is query only. (If you would like to determine only this v alue, use
the WFMOutpre:XINcr? query.)
MSO54, MSO56, MSO58, MSO58LP Programmer D-9
