Command groups
Table 2-40: Trigger commands (cont.)
Command
Description
TRIGger:{A|B}:LOGICPattern:
{CH<x>|CH<x>_D<x>}
Sets or queries the Logic Pattern that is used along with the Define Logic choice to
determine when the logic trigger occurs.
TRIGger:{A|B}:LOWerthreshold:CH<x> Sets or queries CH<x> lower trigger level.
TRIGger:{A|B}:PULSEWidth:
LOGICQUALification
Sets whether or not to use logic qualification for a pulse width trigger.
TRIGger:{A|B}:PULSEWidth:HIGHLimit Specifies the upper limit to use, in seconds, when triggering on detection of a pulse
whose duration is inside or outside a range of two values.
TRIGger:{A|B}:PULSEWidth:LOWLimit Specifies the lower limit to use, in seconds, when triggering on detection of a pulse
whose duration is inside or outside a range of two values.
TRIGger:{A|B}:PULSEWidth:POLarity Specifies the polarity for a pulse width trigger.
TRIGger:{A|B}:PULSEWidth:SOUrce Specifies the source waveform for a pulse width trigger.
TRIGger:{A|B}:PULSEWidth:WHEn Specifies to trigger when a pulse is detected with a width (duration) that is less than,
greater than, equal to, or unequal to a specified value.
TRIGger:{A|B}:RUNT:LOGICQ UALification Specifies whether or not to use logic qualification for a runt trigger.
TRIGger:{A|B}:RUNT:POLarity Specifies the polarity for the runt trigger.
TRIGger:{A|B}:RUNT:SOUrce Specifies the source waveform for the runt trigger.
TRIGger:{A|B}:RUNT:WHEn Specifies the type of pulse width the trigger checks for w hen it detects a runt.
TRIGger:{A|B}:RUNT:WIDth Specifies the width, in seconds, for a runt trigger.
TRIGger:{A|B}:SETHold:CLOCk:EDGE Specifies the clock edge polarity for setup and hold triggering.
TRIGger:{A|B}:SETHold:CLOCk:SOUrce Specifies the clock source for the setup and hold triggering.
TRIGger:{A|B}:SETHold:HOLDTime Specifies the hold time for setup and hold violation triggering.
TRIGger:{A|B}:SETHold:SETTime Specifies the setup time for setup and hold violation triggering.
TRIGger:{A|B}:SETHOLDLogicval:
{CH<x>|CH<x>_D<x>}
Sets or queries whether the specified channel is included (INCLude) or not included
(DONTInclude) in the Setup & Hold trigger input configuration.
TRIGger:{A|B}:TIMEOut:
LOGICQUALification
Specifies whether or not to use logic qualification for a timeout trigger.
TRIGger:{A|B}:TIMEOut:POLarity When triggering using the TIMEOut trigger type, this commands speci fies the
polarity to be used.
TRIGger:{A|B}:TIMEOut:SO Urce When triggering using the TIMEOut trigger type, this command specifies the source.
TRIGger:{A|B}:TIMEOut:T IM e When triggering using the TIMEOut trigger type, this command specifies the
timeout time, in seconds.
TRIGger:{A|B}:TRANsition:DELTatime Specifies the delta time used in calculating the transition value for the transition
trigger.
TRIGger:{A|B}:TRANsition:POLarity Specifies the polarity for the transition trigger.
TRIGger:{A|B}:TRANsition:SOUrce Specifies the source for a transition trigger.
TRIGger:{A|B}:TRANsition:WHEn Specifies whether to check for a transitioning signal that is faster or slower than
the specified delta time.
TRIGger:{A|B}:TRANsition:
LOGICQUALification
Specifies whether or not to use logic qualification for a transition trigger.
TRIGger:{A|B}:TYPe Sets or queries the type of A or B trigger.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-83
