Table 83 CRIMP TOOLS FOR OTHER TERMINAL LUGS (Continued)
Terminal Lug
Crimp
Barrel Size
Crimp Tool
Basic Unit Setting Holder Head Nest Die
53580-1 16
59250 - - - - Blue
69875-H - - 69875 - -
54746-1 6
59974-1 - - - - 47822
Power Pump - - 69061 - 47821
NOTE: Refer to Table 40 for the part numbers of the recommended Power Pumps.
NOTE: Refer to Subject 20-30-22 for the assembly of a terminal lug with a conductor that is smaller
than the crimp barrel size of the terminal lug.
(1) Make a selection of a:
• BACT12AB terminal lug from Table 28
• BACT12AM terminal lug from Table 30
• BACT12S terminal lug from Table 32
• Rolls-Royce terminal lug from Table 34
• Thermocouple terminal lug from Table 37 or a
• Terminal lug from Table 38.
NOTE: For the selection of the terminal, use:
• The crimp barrel size, if one wire is to be terminated
• The CAU range, if more than one wire is to be terminated.
NOTE: Refer to Subject 20-30-22 if more than one wire is to be terminated.
(2) Make a selection of a crimp tool from:
• Table 76 for BACT12AB terminal lugs
• Table 77 for BACT12AM terminal lugs
• Table 78 for BACT12S terminal lugs
• Table 79 for Rolls-Royce terminal lugs
• Table 80 for thermocouple terminal lugs
• Table 81 for a 69B40570-() terminal lug
• Table 83 for other terminal lugs.
(3) If the crimp tool basic unit is a power pump, adjust the pressure to make it satisfactory for the
crimp tool head. Refer to Table 41.
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 114
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
