Table 105 SPLICE ASSEMBLY CONFIGURATIONS (Continued)
One End of Splice Assembly Other End of Splice Assembly
Quantity of
Conductor
Splices
Paragraph
One Shielded Wire and One Wire One Shielded Wire 1 Paragraph 14.D.
One Class 2 Shielded Cable
One Class 2 Shielded Cable 2 Paragraph 14.G.
One Class 2 Shielded Cable and One
Wire
2 Paragraph 14.H.
Two Class 2 Shielded Cables
Two Class 2 Shielded Cables 2 Paragraph 14.I.
Three Class 2 Shielded Cables 2 Paragraph 14.J.
Three Class 2 Shielded Cables
Two Class 2 Shielded Cables 2 Paragraph 14.J.
Three Class 2 Shielded Cables 2 Paragraph 14.K.
One Class 2 Shielded Cable and One
Wire
One Class 2 Shielded Cable 2 Paragraph 14.H.
One Class 3 Shielded Cable
Three Shielded Wires 3 Paragraph 14.L.
One Class 3 Shielded Cable 3 Paragraph 14.M.
Two Class 3 Shielded Cables 3 Paragraph 14.N.
Three Class 3 Shielded Cables 3 Paragraph 14.O.
Two Class 3 Shielded Cables
One Class 3 Shielded Cable 3 Paragraph 14.N.
Two Class 3 Shielded Cables 3 Paragraph 14.P.
Three Class 3 Shielded Cables 3 Paragraph 14.Q.
Three Class 3 Shielded Cables
One Class 3 Shielded Cable 3 Paragraph 14.O.
Two Class 3 Shielded Cables 3 Paragraph 14.Q.
One Class 4 Shielded Cable One Class 4 Shielded Cable 4 Paragraph 14.R.
(1) Find the paragraph for the splice assembly configuration in Table 105.
Make sure the paragraph is applicable for:
• The configuration of the wiring
• The quantity of conductor splices.
(2) Make a selection of a splice kit. Refer to the applicable paragraph for the splice assembly
configuration.
NOTE: The specified splice kit can have more splices and sleeves than are necessary. Discard
the unwanted parts.
(a) Measure these dimensions of the wire or cable on each side of the splice:
• The jacket O.D.
• The shield O.D.
(b) Calculate the total CAU of the conductors for each end of each conductor splice. Refer to
Paragraph 1.D.
(c) If the jackets do not have the correct O.D. for the splice kit, make a selection of an
alternative splice configuration. Refer to Paragraph 1.C.
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 292
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
