Command groups
Table 2-31: Measurement commands (cont.)
Command
Description
MEASUrement:MEAS<x>:CLOCKRecovery:
JTFBandwidth
This command sets or queries the JTF bandwidth used when PLL clock recovery
is used for the measurement.
MEASUrement:MEAS<x>:CLOCKRecovery:
LOOPBandwidth
This command sets or queries the loop bandwidth used when PLL clock recovery
is used for the measurement.
MEASUrement:MEAS<x>:CLOCKRecovery:
MEANAUTOCalculate
This command sets or queries how often the clock is calculated when constant clock
recovery is used for the measurement.
MEASUrement:MEAS<x>:CLOCKRecovery:
METHod
This command sets or queries the clock recovery method for the measurement.
MEASUrement:MEAS<x>:CLOCKRecovery:
MODel
This command sets or queries the PLL clock recovery model used when PLL clock
recovery is used for the measurement.
MEASUrement:MEAS<x>:CLOCKRecovery:
NOMINALOFFset
This command sets or queries the offset value used when explicit clock recovery
is used for the measurement.
MEASUrement:MEAS<x>:CLOCKRecovery:
NOMINALOFFset:SELECTIONtype
This command sets or queries the offset type used when explicit clock recovery is
used for the measurement.
MEASUrement:MEAS<x>:CLOCKRecovery:
STAndard
This command sets or queries the communications standard w hen PLL clock recovery
is used for the measurement.
MEASUrement:MEAS<x>:COMMONMode:
FILTers:STATE
This command sets or queries whether a lter is used for the measurement when the
measurement type is AC common mode.
MEASUrement:MEAS<x>:COMMONMode:
SOURCEs
This command sets or queries the number of sources for the measurement when the
measurement type is AC common mode.
MEASUrement:MEAS<x>:CYCLemode This command sets or queries the cycle mode for the measurement.
MEASUrement:MEAS<x>:DELay:EDGE<x> This command sets or queries the 'to edge' type when EDGE? is EDGE1 and the
'from edge' type when EDGE? is EDG2, for the measurement when the measurement
type is DELAY.
MEASUrement:MEAS<x>:DISPlaystat:ENABle Turns on and off the display of statistics in measurement badges.
MEASUrement:MEAS<x>:EDGE<x> This command sets or queries the type of the specied edge, rise or fall, for the
measurement.
MEASUrement:MEAS<x>:EDGEIncre This command sets or queries the edge increment value for the m easurement.
MEASUrement:MEAS<x>:EDGES:FROMLevel This command sets or queries the 'from level' edge for the measurement.
MEASUrement:MEAS<x>:EDGES:LEVel This sets or queries the level type for the 'time outside level' measurement.
MEASUrement:MEAS<x>:EDGES:
LOWERFREQuency
This command sets or queries the lower frequency for the measurement when the
measurement type is phase noise. Lower frequencies are ignored.
MEASUrement:MEAS<x>:EDGES:N The command sets or queries the number of accumulation cycles for the measurement
when the measurement type is nperiod.
MEASUrement:MEAS<x>:EDGES:
SLEWRATEMethod
This command sets or queries the slew rate method for the measurement.
MEASUrement:MEAS<x>:EDGES:TOLevel This command sets or queries the 'to level' edge for the measurement.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-45
