Tektronix MSO58 User Manual

Command groups
Table 2-34: Power commands (cont.)
Command Description
POWer:POWer<x>:SOA:POINT Sets or queries the Y co-ordinate value for SOA mask.
POWer:POWer<x>:SOA:POINT Sets or queries the X co-ordinate value for SOA mask.
POWer:POWer<x>:SOA:
RECAllmask
Recalls or queries the recall mask file name in the specified power measurement badge.
POWer:POWer<x>:SOA:
RECAllmask:FILEName
Sets or queries the file name for saving SOA mask file name in the specified power
measurement badge.
POWer:POWer<x>:SOA:
SAVemask
Saves the mask file as per the name configured and at the configured path or queries the mask
file name, path, and file type for the SOA m easurement in the specified power measurement
badge.
POWer:POWer<x>:SOA:
SAVemask:AUTOINCrement
Sets or queries the state of auto-increment for saved SOA mask file names in the specified
power measurement badge.
POWer:POWer<x>:SOA:
SAVemask:FILEName
Sets or queries the mask file name for SOA measurement in the specified power measurement
badge.
POWer:POWer<x>:SOA:
SAVemask:FOLDer
Sets or queries the mask file folder path for SOA measurement in the specified power
measurement badge.
POWer:POWer<x>:SOA:
VSOURce
Sets or queries the voltage source for SOA measurement in the specified power measurement
badge.
POWer:POWer<x>:
SWITCHINGLOSS:DEVICEType
Sets or queries the conduction calculation method for switching loss measurement in the
specified power measurement badge.
POWer:POWer<x>:
SWITCHINGLOSS:GATESOurce
Sets or queries the gate voltage (V
g
) for the switching loss measurement in the specified
power measurement badge.
POWer:POWer<x>:
SWITCHINGLOSS:ILEVELAbs
Sets or queries the current level (Ton-Start & Stop) in absolute units for switching loss
measurement in the specified power measurement badge.
POWer:POWer<x>:
SWITCHINGLOSS:ILEVELPct
Sets or queries the current level (Ton-Star t & Stop) in percentage for switching loss
measurement in the specified power measurement badge.
POWer:POWer<x>:
SWITCHINGLO SS:ISOURce
Sets or queries the current source for the switching loss measurement in the specified power
measurement badge.
POWer:POWer<x>:
SWITCHINGLOSS:LEVELUNIts
Sets or queries the level units for switching loss measurement in the specified power
measurement badge.
POWer:POWer<x>:
SWITCHINGLO SS:R DSOn
Sets or queries the RDS(on) value for switching loss measurement in the specified power
measurement badge.
POWer:POWer<x>:
SWITCHINGLO SS:
SWLCONFIGType
Sets or queries the configuration type for the switching loss measurement in the specified
power measurement badge.
POWer:POWer<x>:
SWITCHINGLOSS:VCESat
Sets or queries the value for the VCE(sat) value for switching loss measurement in the
specified power measurement badge.
POWer:POWer<x>:
SWITCHINGLOSS:VGLevel
Sets or queries the gate voltage value (V
g
Level Ton-Start) for the switching loss measurement
in the specified power measurement badge.
POWer:POWer<x>:
SWITCHINGLOSS:VLEVELAbs
Sets or queries the voltage level (Ton-Start & Stop) in absolute units for switching loss
measurement in the specified power measurement badge.
POWer:POWer<x>:
SWITCHINGLOSS:VLEVELPct
Sets or queries the voltage level (Ton-Start & Stop) in percentage for switching loss
measurement in the specified power measurement badge.
2-60 MSO54, MSO56, MSO58, MSO58LP Programmer
