Command groups
Table 2-40: Trigger commands (cont.)
Command
Description
TRIGger:{A|B}:BUS:B<x>:FLEXray:DATa:
QUALifier
Specifies the qualifier (<, >, =, <=, >=, ≠, in range, out of range) to use when
triggering on the FlexRay bus data field.
TRIGger:{A|B}:BUS:B<x>:FLEXray:DATa:
SIZe
Specifies the length of the data s tring, in bytes, when triggering on the FlexRay
bus data field.
TRIGger:{A|B}:BUS:B<x>:FLEXray:DATa:
VALue
Specifies the low value w hen triggering on the FlexRay bus data field.
TRIGger:{A|B}:BUS:B<x>:FLEXray:
EOFTYPE
Specifies the end of file type (static, dynamic or any) when triggering on the FlexRay
bus EOF field.
TRIGger:{A|B}:BUS:B<x>:FLEXray:
ERRTYPE
Specifies the error type when triggering on the FlexRay bus signal.
TRIGger:{A|B}:BUS:B<x>:FLEXray:
FRAMEID:HIVALue
Specifies the high value when triggering on the FlexRay bus frame ID field.
TRIGger:{A|B}:BUS:B<x>:FLEXray:
FRAMEID:QUALifier
Specifies the qualifier to use when triggering on the FlexRay bus frame ID field.
TRIGger:{A|B}:BUS:B<x>:FLEXray:
FRAMEID:VALue
Specifies the low value when triggering on the FlexRay bus frame ID field.
TRIGger:{A|B}:BUS:B<x>:FLEXray:
FRAMEType
Specifies the frame type (normal, payload, null, sync or startup) when triggering on
the FlexRay bus signal.
TRIGger:{A|B}:BUS:B<x>:FLEXray:
HEADER:CRC
Specifies the CRC portion of the binary header string when triggering on the FlexRay
bus signal.
TRIGger:{A|B}:BUS:B<x>:FLEXray:
HEADER:CYCLEcount
Specifies the cycle count portion of the binary header string when triggering on
the FlexRay bus header.
TRIGger:{A|B}:BUS:B<x>:FLEXray:
HEADER:FRAMEID
Specifies the frame ID portion of the b inary header string when triggering on the
FlexRay bus header.
TRIGger:{A|B}:BUS:B<x>:FLEXray:
HEADER:INDBits
Specifies the indicator bits portion of the binary header string when triggering on
the FlexRay bus header.
TRIGger:{A|B}:BUS:B<x>:FLEXray:
HEADER:PAYLength
Specifies the payload length portion of the binary header string when triggering on
the FlexRay bus header.
TRIGger:{A|B}:BUS:B <x >:I2C:ADDRess:
MODe
Specifies the I
2
C address mode to 7 or 10-bit.
TRIGger:{A|B}:BUS:B <x >:I2C:ADDRess:
VALue
Specifies the binary address string used for the I
2
C trigger if the trigger condition is
ADDRESS or ADDRANDDATA.
TRIGger:{A|B}:BUS:B <x>:I2C:CONDition Specifies the trigger condition for an I
2
C trigger.
TRIGger:{A|B}:BUS:B <x>:I2C:DATa:
DIRection
Specifies the I
2
C trigger type to be valid on a Read, Write, or No Care condition.
TRIGger:{A|B}:BUS:B <x>:I2C:DATa:SIZe Specifies the length of the data string in bytes to be used for an I2C trigger if the
trigger condition is DATA or ADDRANDDATA.
TRIGger:{A|B}:BUS:B<x>:I2C:DATa:VALue Specifies the binary data string used for I2C triggering if the trigger condition is
DATA or ADDRANDDATA.
TRIGger:{A|B}:BUS:B<x>:LIN:CONDition Specifies the trigger condition for LIN.
TRIGger:{A|B}:BUS:B<x>:LIN:DATa:HIVALue Specifies the high data value string used for a LIN bus trigger when the trigger
condition is DATA or IDANDDATA and the data qualifier is INRANGE or O U TRANGE.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-79
