Table 21-2. LINFlex memory map
Address offset Register Location
0x0000 LIN control register 1 (LINCR1) on page 385
0x0004 LIN interrupt enable register (LINIER) on page 388
0x0008 LIN status register (LINSR) on page 389
0x000C LIN error status register (LINESR) on page 392
0x0010 UART mode control register (UARTCR) on page 393
0x0014 UART mode status register (UARTSR) on page 394
0x0018 LIN timeout control status register (LINTCSR) on page 396
0x001C LIN output compare register (LINOCR) on page 397
0x0020 LIN timeout control register (LINTOCR) on page 398
0x0024 LIN fractional baud rate register (LINFBRR) on page 398
0x0028 LIN integer baud rate register (LINIBRR) on page 399
0x002C LIN checksum field register (LINCFR) on page 400
0x0030 LIN control register 2 (LINCR2) on page 400
0x0034 Buffer identifier register (BIDR) on page 401
0x0038 Buffer data register LSB (BDRL)
1
on page 402
0x003C Buffer data register MSB (BDRM)
2
on page 403
0x0040 Identifier filter enable register (IFER) on page 404
0x0044 Identifier filter match index (IFMI) on page 405
0x0048 Identifier filter mode register (IFMR) on page 406
0x004C Identifier filter control register 0 (IFCR0) on page 407
0x0050 Identifier filter control register 1 (IFCR1) on page 408
0x0054 Identifier filter control register 2 (IFCR2) on page 408
0x0058 Identifier filter control register 3 (IFCR3) on page 408
0x005C Identifier filter control register 4 (IFCR4) on page 408
0x0060 Identifier filter control register 5 (IFCR5) on page 408
0x0064 Identifier filter control register 6 (IFCR6) on page 408
0x0068 Identifier filter control register 7 (IFCR7) on page 408
0x006C Identifier filter control register 8 (IFCR8) on page 408
0x0070 Identifier filter control register 9 (IFCR9) on page 408
0x0074 Identifier filter control register 10 (IFCR10) on page 408
0x0078 Identifier filter control register 11 (IFCR11) on page 408
0x007C Identifier filter control register 12 (IFCR12) on page 408
0x0080 Identifier filter control register 13 (IFCR13) on page 408
