Network structures
6.1 WLAN
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
Configuration Manual, 11/2014, C79000-G8976-C351-03
151
You are in the Interface Configuration mode of the WLAN interface.
The command prompt is as follows:
cli (config-if-wlan-0-X)#
Call up the command with the following parameters:
wlan antenna gain-5GHz <index(1)> <dBi (0-30)>
The parameters have the following meaning:
Values or range of values
Slot no. of the interface
Antenna gain in decibels iso-
tropic (dBi)
0 ... 30
0 = antenna is not connected
The antenna gain is specified.
You show the set antenna gain with the show wlan antennas <wlan 0/X> command.
wlan antenna type
Description
With this command, you specify which antenna type is connected to the relevant antenna
connector.
You are in the Interface Configuration mode of the WLAN interface.
The command prompt is as follows:
cli (config-if-wlan-0-X)#
