Network structures
6.1 WLAN
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
Configuration Manual, 11/2014, C79000-G8976-C351-03
195
wds connection over (access point)
Description
With this command, you specify the VAP interface via which the WDS connection is
established.
Note
This command is available only in access point mode.
You are in the Interface Configuration mode for the WDS interface.
The command prompt is as follows:
cli (config-if-wdsX-0-Y)#
Call up the command with the following parameters:
wds conncection over <vapX 0/Y>
The parameter has the following meaning:
Values or range of values
For information on identifiers of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 23)".
The VAP interface is set.
You display the setting with the show wlan wds <wdsX 0/Y> command.
