Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual I – 7
Index
Solenoid tests, 11-9
test descriptions, 11-5
test print generation, 4-2
servicing instructions, 3-3
Single Tray Module
L/H Cover Assembly
removal, 8-122
L/H Cover Switch
operation, 2-52
removal, 8-125
operation, 2-51
PWB
operation, 2-52
part number, 9-69
removal, 8-120
removal, 8-129
T/A Motor Assembly
operation, 2-52
part number, 9-69
removal, 8-119
Tray 3
Feed Out Sensor
operation, 2-52
removal, 8-121
Feed Roller Kit
removal, 8-117
Feed/ Lift Up Motor
operation, 2-51
removal, 8-115
Feeder Assembly
removal, 8-112
No Paper Sensor
operation, 2-51
removal, 8-116
Nudger Level Sensor
operation, 2-51
removal, 8-116
Paper Size Sensor
operation, 2-51
removal, 8-114
wiring diagram, 10-55
Solenoid tests, 11-9
specifications
electrical, 1-13
environment, 1-13
image, 1-18
memory, 1-13
mounting surface, 1-23
paper and tray, 1-19
printer, 1-12
print-quality, 1-18, 5-20
Startup page
POST error reports, 4-5
Status Messages and Codes, 3-14
T
technical support, 1-2
test print
Service Diagnostics test prints, 11-5
Toner Cartridge
non-Xerox Toner Cartridge
Control Panel display, 1-25
operation, 2-31
part number, 9-27, 9-114
removal, 8-9
Toner Dispenser Motor
operation, 2-32
part number, 9-27
removal, 8-43
wiring diagram, 10-44
Toner Sensors
wiring diagram, 10-51
Tray 1
Feed Out Sensor
operation, 2-43
part number, 9-81
removal, 8-137
Feed Roller Kit
part number, 9-115
removal, 8-135
Feed/ Nudger Motor
operation, 2-42
removal, 8-132
Feed/ Nudger Roll
part number, 9-79
Feeder Assembly
part number, 9-75
removal, 8-130
No Paper Sensor
operation, 2-42
part number, 9-81
removal, 8-133
Nudger Position Sensor
operation, 2-43
part number, 9-77
removal, 8-138
Paper Size Sensor
operation, 2-42
part number
, 9-83
removal, 8-139
removal, 8-131
Retard Roll
part number, 9-81
wiring diagram, 10-52
Tray 2
Feed Roller Kit
removal, 8-87
Feed/ Lift Up Motor
operation, 2-41
part number, 9-48
removal, 8-85
Feeder Assembly
operation, 2-41
part number, 9-46
removal, 8-83
No Paper Sensor
operation, 2-41
part number, 9-48
removal, 8-86

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
