BPswitch Operators Manual
370 / 413
button will illuminate red, as shown on
the right.
The [>] motion control button may also
be used to start streaming
To stop streaming:
In Device Control section, select the [Stream] PixButton,
it will illuminate orange, as shown on the right.
In the PixPad select the [Stop Stream] PixButton, as
shown on the right.
The counter will stop, the display will read out ready to
stream and the motion control button will illuminate
orange, as shown on the right.
The [>] motion control button may also be used to stop
streaming.
In addition, Macros can be used to start and stop the
Stream device, once a Profile/Job has been selected.
Recording
Every BPswitch system has the ability to record the Program output directly to the
internal hard drive of the system. The Program video output from the Broadcast
Pix software is automatically sent to the recorder through software and the audio
comes from the Master output of the internal audio mixer, as described in Audio
Mixer. Audio is automatically synchronized with the video, to guarantee constant
lip-sync.
The recorded file is a broadcast quality 1920x1080i Motion JPEG .avi file. 1 hour
of recorded content equals around 20 GB on disk. Currently recording only to the
System C or Video D drive is supported, using any other external hard drive in
unsupported any may cause system performance issues.
The created file can then be imported directly into the clip store for playback or
into a 3
rd
party editing system or play out device.
