Dimensions
Inches: 19 x 5.25 x 20.8
Centimeters: 48.3 x 13.3 x 52.8
Rack units
3 RU
Weight
32 Lbs / 14.5 Kg
Power
500 watts
Power Consumption
Typical: 132VA @240VAC / 450 BTU/hr
Max: 500VA @240VAC / 1700 BTU/hr ?
500 Control Panel Specifications
Dimensions
Inches: 15.2 x 9.3 x 4
Centimeters: 39 x 24 x 10 ?
Weight
5 Lbs / 2 Kg
Power
(1) 30 watt power supply (redundant one optional)
1000 Control Panel Specifications
Dimensions
Inches: 18.5 x 12.5 x 5.5
Centimeters: 47 x 32 x 14 ?
Weight
7 Lbs / 3 Kg
Power
(1)45 watt power supply (redundant one optional)
5 – 265 VAC, 47 – 63Hz, -10 to +70 degrees Celsius
Power Consumption
Typical: 26VA @240VAC / 90 BTU/hr Max: 60VA @240VAC /
200 BTU/hr
2000 Control Panel Specifications
Dimensions
Inches: 27.5 x 12.5 x 7
Centimeters: 70 x 32 x 18 ?
Weight
16.2 Lbs / 7.3 Kg
Power
(2) Redundant 50 watt power supplies
85 – 265 VAC, 47 – 63Hz, -10 to +70 degrees Celsius
Power Consumption
Typical: 26VA @240VAC / 90 BTU/hr Max: 60VA @240VAC /
200 BTU/hr
