28.3.18 ADC Minus-Side General Calibration Value Register
(ADCx_CLMD)
The Minus-Side General Calibration Value (CLMx) registers contain calibration
information that is generated by the calibration function. These registers contain seven
calibration values of varying widths: CLM0[5:0], CLM1[6:0], CLM2[7:0], CLM3[8:0],
CLM4[9:0], CLMS[5:0], and CLMD[5:0]. CLMx are automatically set when the self-
calibration sequence is done, that is, CAL is cleared. If these registers are written by the
user after calibration, the linearity error specifications may not be met.
Address: 4003_B000h base + 54h offset = 4003_B054h
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
0
CLMD
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 1 0
ADCx_CLMD field descriptions
Field Description
31–6
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
5–0
CLMD
Calibration Value
28.3.19 ADC Minus-Side General Calibration Value Register
(ADCx_CLMS)
For more information, see CLMD register description.
Address: 4003_B000h base + 58h offset = 4003_B058h
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
0
CLMS
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0
ADCx_CLMS field descriptions
Field Description
31–6
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
5–0
CLMS
Calibration Value
Chapter 28 Analog-to-Digital Converter (ADC)
KL25 Sub-Family Reference Manual, Rev. 3, September 2012
Freescale Semiconductor, Inc. 479
