UARTx_BDH field descriptions (continued)
Field Description
4–0
SBR
Baud Rate Modulo Divisor.
The 13 bits in SBR[12:0] are referred to collectively as BR, and they set the modulo divide rate for the
baud rate generator. When BR is 1 - 8191, the baud rate equals baud clock / ((OSR+1) × BR).
39.2.2 UART Baud Rate Register Low (UARTx_BDL)
This register, along with UART _BDH, control the prescale divisor for UART baud rate
generation. The 13-bit baud rate setting [SBR12:SBR0] can only be updated when the
transmitter and receiver are both disabled.
UART _BDL is reset to a non-zero value, so after reset the baud rate generator remains
disabled until the first time the receiver or transmitter is enabled; that is, UART _C2[RE]
or UART _C2[TE] bits are written to 1.
Address: Base address + 1h offset
Bit 7 6 5 4 3 2 1 0
Read
SBR
Write
Reset
0 0 0 0 0 1 0 0
UARTx_BDL field descriptions
Field Description
7–0
SBR
Baud Rate Modulo Divisor
These 13 bits in SBR[12:0] are referred to collectively as BR. They set the modulo divide rate for the baud
rate generator. When BR is 1 - 8191, the baud rate equals baud clock/((OSR+1) × BR).
39.2.3 UART Control Register 1 (UARTx_C1)
This read/write register controls various optional features of the UART system. This
register should only be altered when the transmitter and receiver are both disabled.
Address: Base address + 2h offset
Bit 7 6 5 4 3 2 1 0
Read
LOOPS DOZEEN RSRC M WAKE ILT PE PT
Write
Reset
0 0 0 0 0 0 0 0
Register definition
