TPM memory map (continued)
Absolute
address
(hex)
Register name
Width
(in bits)
Access Reset value
Section/
page
4003_9000 Status and Control (TPM1_SC) 32 R/W 0000_0000h 31.3.1/552
4003_9004 Counter (TPM1_CNT) 32 R/W 0000_0000h 31.3.2/553
4003_9008 Modulo (TPM1_MOD) 32 R/W 0000_FFFFh 31.3.3/554
4003_900C Channel (n) Status and Control (TPM1_C0SC) 32 R/W 0000_0000h 31.3.4/555
4003_9010 Channel (n) Value (TPM1_C0V) 32 R/W 0000_0000h 31.3.5/557
4003_9014 Channel (n) Status and Control (TPM1_C1SC) 32 R/W 0000_0000h 31.3.4/555
4003_9018 Channel (n) Value (TPM1_C1V) 32 R/W 0000_0000h 31.3.5/557
4003_901C Channel (n) Status and Control (TPM1_C2SC) 32 R/W 0000_0000h 31.3.4/555
4003_9020 Channel (n) Value (TPM1_C2V) 32 R/W 0000_0000h 31.3.5/557
4003_9024 Channel (n) Status and Control (TPM1_C3SC) 32 R/W 0000_0000h 31.3.4/555
4003_9028 Channel (n) Value (TPM1_C3V) 32 R/W 0000_0000h 31.3.5/557
4003_902C Channel (n) Status and Control (TPM1_C4SC) 32 R/W 0000_0000h 31.3.4/555
4003_9030 Channel (n) Value (TPM1_C4V) 32 R/W 0000_0000h 31.3.5/557
4003_9034 Channel (n) Status and Control (TPM1_C5SC) 32 R/W 0000_0000h 31.3.4/555
4003_9038 Channel (n) Value (TPM1_C5V) 32 R/W 0000_0000h 31.3.5/557
4003_9050 Capture and Compare Status (TPM1_STATUS) 32 R/W 0000_0000h 31.3.6/557
4003_9084 Configuration (TPM1_CONF) 32 R/W 0000_0000h 31.3.7/559
4003_A000 Status and Control (TPM2_SC) 32 R/W 0000_0000h 31.3.1/552
4003_A004 Counter (TPM2_CNT) 32 R/W 0000_0000h 31.3.2/553
4003_A008 Modulo (TPM2_MOD) 32 R/W 0000_FFFFh 31.3.3/554
4003_A00C Channel (n) Status and Control (TPM2_C0SC) 32 R/W 0000_0000h 31.3.4/555
4003_A010 Channel (n) Value (TPM2_C0V) 32 R/W 0000_0000h 31.3.5/557
4003_A014 Channel (n) Status and Control (TPM2_C1SC) 32 R/W 0000_0000h 31.3.4/555
4003_A018 Channel (n) Value (TPM2_C1V) 32 R/W 0000_0000h 31.3.5/557
4003_A01C Channel (n) Status and Control (TPM2_C2SC) 32 R/W 0000_0000h 31.3.4/555
4003_A020 Channel (n) Value (TPM2_C2V) 32 R/W 0000_0000h 31.3.5/557
4003_A024 Channel (n) Status and Control (TPM2_C3SC) 32 R/W 0000_0000h 31.3.4/555
4003_A028 Channel (n) Value (TPM2_C3V) 32 R/W 0000_0000h 31.3.5/557
4003_A02C Channel (n) Status and Control (TPM2_C4SC) 32 R/W 0000_0000h 31.3.4/555
4003_A030 Channel (n) Value (TPM2_C4V) 32 R/W 0000_0000h 31.3.5/557
4003_A034 Channel (n) Status and Control (TPM2_C5SC) 32 R/W 0000_0000h 31.3.4/555
4003_A038 Channel (n) Value (TPM2_C5V) 32 R/W 0000_0000h 31.3.5/557
4003_A050 Capture and Compare Status (TPM2_STATUS) 32 R/W 0000_0000h 31.3.6/557
4003_A084 Configuration (TPM2_CONF) 32 R/W 0000_0000h 31.3.7/559
Chapter 31 Timer/PWM Module (TPM)
KL25 Sub-Family Reference Manual, Rev. 3, September 2012
Freescale Semiconductor, Inc. 551
