29.7.3 CMP Filter Period Register (CMPx_FPR)
Address: 4007_3000h base + 2h offset = 4007_3002h
Bit 7 6 5 4 3 2 1 0
Read
FILT_PER
Write
Reset
0 0 0 0 0 0 0 0
CMPx_FPR field descriptions
Field Description
7–0
FILT_PER
Filter Sample Period
Specifies the sampling period, in bus clock cycles, of the comparator output filter, when CR1[SE]=0.
Setting FILT_PER to 0x0 disables the filter. Filter programming and latency details appear in the
Functional description.
This field has no effect when CR1[SE]=1. In that case, the external SAMPLE signal is used to determine
the sampling period.
29.7.4 CMP Status and Control Register (CMPx_SCR)
Address: 4007_3000h base + 3h offset = 4007_3003h
Bit 7 6 5 4 3 2 1 0
Read 0
DMAEN
0
IER IEF
CFR CFF COUT
Write w1c w1c
Reset
0 0 0 0 0 0 0 0
CMPx_SCR field descriptions
Field Description
7
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
6
DMAEN
DMA Enable Control
Enables the DMA transfer triggered from the CMP module. When this field is set, a DMA request is
asserted when CFR or CFF is set.
0 DMA is disabled.
1 DMA is enabled.
5
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
4
IER
Comparator Interrupt Enable Rising
Enables the CFR interrupt from the CMP. When this field is set, an interrupt will be asserted when CFR is
set.
Table continues on the next page...
