USB memory map (continued)
Absolute
address
(hex)
Register name
Width
(in bits)
Access Reset value
Section/
page
4007_209C BDT Page Register 1 (USB0_BDTPAGE1) 8 R/W 00h
35.4.16/
636
4007_20A0 Frame Number Register Low (USB0_FRMNUML) 8 R/W 00h
35.4.17/
636
4007_20A4 Frame Number Register High (USB0_FRMNUMH) 8 R/W 00h
35.4.18/
637
4007_20A8 Token register (USB0_TOKEN) 8 R/W 00h
35.4.19/
637
4007_20AC SOF Threshold Register (USB0_SOFTHLD) 8 R/W 00h
35.4.20/
638
4007_20B0 BDT Page Register 2 (USB0_BDTPAGE2) 8 R/W 00h
35.4.21/
639
4007_20B4 BDT Page Register 3 (USB0_BDTPAGE3) 8 R/W 00h
35.4.22/
639
4007_20C0 Endpoint Control register (USB0_ENDPT0) 8 R/W 00h
35.4.23/
639
4007_20C4 Endpoint Control register (USB0_ENDPT1) 8 R/W 00h
35.4.23/
639
4007_20C8 Endpoint Control register (USB0_ENDPT2) 8 R/W 00h
35.4.23/
639
4007_20CC Endpoint Control register (USB0_ENDPT3) 8 R/W 00h
35.4.23/
639
4007_20D0 Endpoint Control register (USB0_ENDPT4) 8 R/W 00h
35.4.23/
639
4007_20D4 Endpoint Control register (USB0_ENDPT5) 8 R/W 00h
35.4.23/
639
4007_20D8 Endpoint Control register (USB0_ENDPT6) 8 R/W 00h
35.4.23/
639
4007_20DC Endpoint Control register (USB0_ENDPT7) 8 R/W 00h
35.4.23/
639
4007_20E0 Endpoint Control register (USB0_ENDPT8) 8 R/W 00h
35.4.23/
639
4007_20E4 Endpoint Control register (USB0_ENDPT9) 8 R/W 00h
35.4.23/
639
4007_20E8 Endpoint Control register (USB0_ENDPT10) 8 R/W 00h
35.4.23/
639
4007_20EC Endpoint Control register (USB0_ENDPT11) 8 R/W 00h
35.4.23/
639
4007_20F0 Endpoint Control register (USB0_ENDPT12) 8 R/W 00h
35.4.23/
639
4007_20F4 Endpoint Control register (USB0_ENDPT13) 8 R/W 00h
35.4.23/
639
4007_20F8 Endpoint Control register (USB0_ENDPT14) 8 R/W 00h
35.4.23/
639
Table continues on the next page...
Memory map/Register definitions
KL25 Sub-Family Reference Manual, Rev. 3, September 2012
622 Freescale Semiconductor, Inc.
