Phaser 7500 Printer Service Manual I – 3
Index
Rear Cover
part number, 9-111
removal, 8-217
Right Cover
part number, 9-66, 9-111
removal, 8-110, 8-219
Top Cover
part number, 9-66, 9-111
removal, 8-211
Top Rear Cover
part number, 9-111
removal, 8-217
Tray 1 Front Cover
part number, 9-111
removal, 8-214
CPU interrupts error, 4-6
CRUM
operation, 2-30, 2-31
part number, 9-39
D
Developer Housing Assembly
operation, 2-32
part number, 9-29
removal, 8-50
Developer Motors
wiring diagram, 10-42
Developer Unit
part number, 9-29
Dispenser Pipe
part number, 9-27
removal, 8-46, 8-54
Drum/ Deve Drive Assembly
part number, 9-19
removal, 8-33
Duplex Assembly
Cover Switch
operation, 2-56
Motor
operation, 2-56
removal, 8-163
operation, 2-56
part number, 9-85, 9-93, 9-116
removal, 8-161
Wait Sensor
operation, 2-56
removal, 8-166
wiring diagram, 10-53
Duplex Jam Sensor
testing, 11-7
E
EEPROM
error, 4-6
LED EEPROM check, 6-9
electrical
specifications, 1-13
envelopes
supported sizes, 1-21
wrinkling, 4-26
Erase Lamp Unit
Erase Lamp Unit (K)
removal, 8-68
Erase Lamp Unit (Y/M/C)
removal, 8-70
operation, 2-30
part number, 9-39
wiring diagram, 10-39
error messages
abbreviation, 3-4
POST, 4-4
printer status, 3-14
Exit Assembly
part number, 9-100
removal, 8-179
F
Fan
Bottom Fan
part number, 9-25
wiring diagram, 10-48
Drive Fan
operation, 2-47
part number, 9-106
removal, 8-206
Fuser Fan
operation, 2-47
part number, 9-21
removal, 8-38
wiring diagram, 10-45
HV Fan
operation, 2-47
part number, 9-25
removal, 8-40
wiring diagram, 10-48
IBT Fan
part number, 9-23
wiring diagram, 10-39
LV Fan
operation, 2-47
part number, 9-102
removal, 8-195
wiring diagram, 10-49
Process 2 Fan
part number, 9-23
wiring diagram, 10-39
Rear Fan
testing, 11-8
testing, 11-8
fastener types
Posi-Drive screw types, 8-8
precautions, 8-8
Fault History, 3-2
